| Main Specifications |
| Device Type | SuperChassis LA26AC12-R1K03LP1 |
| Form Factor | 2U chassis |
| Supported Motherboards | Motherboard size - ATX 12" x 10", E-ATX 12" x 13", EE-ATX 13" x 13.68". Support up to ATX 12"x13" MB with rear 2.5" HDD option installed |
| Dimensions (WxDxH) | Height 3.5" (89 mm) x Width 17.2" (437 mm) x Depth 25.5" (647 mm) |
| Weight | Gross Weight 69 lbs (31.3 kg) - Net Weight 35.3 lbs (16 kg) |
| Enclosure Color | Black |
| Processor |
| Compatible Processors | Dual and Single Intel and AMD processors |
| Expansion / Connectivity |
| Expansion Slots Total (Free) | 7x low-profile expansion slots |
| Expansion Bays Total (Free) | 12x 3.5" (tool-less) or 2.5" (screw) hot-swap SAS3/SATA drive bay with SES3, Optional 2x 2.5" hot-swap drive bay |
| Backplane |
| SAS/SATA HDD Backplane | 12-Port 2U 12-Port 2U LFF Backplane Supports 12 x SAS3/SATA3/NVMe4 Storage Devices with 1x(2x4) + 4x(1x4) power connectors, co-lay with BPN-SAS3-LA26A-N12, HF, RoHS |
| Front Panel |
| Buttons | Power On/Off button, System Reset button |
| LEDs | Power status LED, HDD activity LED, 2 Network Activity LEDs, Unit Identification (UID) LED, Fan Fail/System Over Heat LED |
| System Cooling |
| Fans/Air Shroud | 3x 8cm high-performance PWM fan(s) |
| System Monitoring |
| System Monitoring | Optional Chassis intrusion switch |
| Environmental |
| Operating Environment | Operating Temperature Range: 5°C - 35°C (41°F - 95°F) |
| Non-Operating Temperature Range: -40°C - 70°C (-40°F - 158°F) |
| Operating Relative Humidity Range: 8% - 90% (non-condensing) |
| Non-Operating Relative Humidity Range: 5% - 95% (non-condensing) |
| Power Supply |
| Power Supply | 1U 800/1000W Redundant Titanium Single Output Power Supply W/PMbus |
| Certification | 80PLUS Titanium Certified |
| Regulatory Safety / EMC | BSMI, CCC, CE/EMC, UL/CB |
| Parts List - (Items Included) |
| Hard Drive Backplane | 1x BPN-SAS3-LA26A-N12 |
| Cable(s) | 1x CBL-0071L |
| Parts | 7x MCP-120-00115-0N, 1x MCP-290-82603-0V, 1x MCP-290-82616-0V, 1x MCP-230-82602-0N |
| Fan(s) | 3x FAN-0181L4 |
| Drive Trays | 12x MCP-220-00184-0B |
| Power Distributor(s) | 1x PDB-PT826-L8824 |
| Power Supply Number | 2x PWS-1K03A-1R |
| Rear Window | 1x MCP-240-82608-0N |
| Optional Parts List |
| Optional Air shroud | MCP-310-29001-0N, MCP-310-82603-0B |
| Optional Cable | CBL-PWCD-0160-IS |
| Optional Parts | MCP-290-00088-0N, MCP-260-00042-0N |
| Optional HDD Kit | MCP-220-82616-0N |
| Optional Label | MCP-410-00017-0N, MCP-410-00016-0N |
| Optional Rail | MCP-290-00053-0N |
| Optional Short Rail | MCP-290-00058-0N |
| Miscellaneous |
| Compatible Motherboards | H12SSL-NT, H12SSL-i, H12SSL-CT, H12SSL-C, H12DSi-NT6, H12DSi-N6, X12DPL-NT6, X12DPL-i6 |
