| Main Specifications |
| Device Type | Network Adapter Card |
| Interface | PCIe 5.0 x16 |
| Dimensions (WxDxH) | 2.71 in. x 6.6 in. (68.90mm x 167.65 mm) |
| Power (W) | 24.9W |
| Networking |
| Port Quantity | Single OSFP InfiniBand and Ethernet |
| Network / Transport Protocol | InfiniBand: IBTA v1.5a |
| Auto-Negotiation: NDR (4 lanes x 100Gb/s per lane) port, NDR200 ( 2 lanes x 100Gb/s per lane ) port, HDR (50Gb/s per lane) port, HDR100 (2 lane x 50Gb/s per lane), EDR (25Gb/s per lane) port, FDR (14.0625Gb/s per lane), 1X/2X/4X SDR (2.5Gb/s per lane) |
| Ethernet: 400GAUI-4 C2M, 400GBASE-CR4 , 200GAUI-2 C2M, 200GAUI-4 C2M, 200GBASE-CR4, 100GAUI-2 C2M, 100GAUI-1 C2M, 100GBASE-CR4, 100GBASE-CR2, 100GBASE-CR1, 50GAUI-2 C2M, 50GAUI-1 C2M, 50GBASE-CR, 50GBASE-R2 , 40GBASE-CR4, 40GBASE-R2, 25GBASE-R, 10GBASE-R, 10GBASE-CX4, 1000BASE-CX, CAUI-4 C2M, 25GAUI C2M, XLAUI C2M , XLPPI, SFI |
| Performance |
| Internal Data Rate | InfiniBand (Default): NDR/NDR200/HDR/HDR100/EDR/FDR/SDR |
| Ethernet: 400/200/100/50/40/10/1 Gb/s Ethernet |
| Miscellaneous |
| Feature(s) | Secure Boot Enabled, Crypto Disabled |
| Environmental Compliance | RoHS Compliant |
| Environmental |
| Operating Environment | Humidity Operational: 10% to 85% relative humidity |
| Temperature Operational: 0°C to 55°C |
| Temperature Non-operational: -40°C to 70°Cb |
| Humidity Non-operational: 10% to 90% relative humidity |
| Altitude (Operational): 3050m |
| Power Supply |
| Regulatory Safety / EMC | Safety: CB / cTUVus / CE |
| EMC: CE / FCC / VCCI / ICES / RCM / KC |
