ConnectX-7 Adapter Card With Secure Boot, PCI Express 5.0 x16, Height, Half Length, Provides Dual Port: QSFP112, Data Transmission Rate: 100GbE (Default speed), Tall Bracket Included - MCX713106AS-CEAT - (AOC-CX7AH0076-ST0)
The NVIDIA ConnectX-7 family of Remote Direct Memory Access (RDMA) network adapters supports InfiniBand and Ethernet protocols and high speeds. It enables a wide range of smart, scalable, and feature-rich networking solutions that address traditional enterprise needs of even the extra demanding AI, scientific computing, and hyperscale cloud data center workloads.
| Main Specifications | ||
| Device Type | Network adapter - 2 ports | |
| Form Factor | Plug-in Card | |
| Interface | PCI Express 5.0 x16 | |
| PCI Specification Revision | PCIe 1.1, PCIe 2.0, PCIe 3.0, PCIe 4.0, PCIe 5.0 | |
| Dimensions (WxDxH) | 2.7 in x 6.6 in | |
| Networking | ||
| Data Link Protocol | 1GbE, 10GbE, 40GbE, 100GbE, 25GbE, 50GbE, 200GbE | |
| Cabling Type | Ethernet 1000Base-CX, Ethernet 10GBase-CX4, Ethernet 10GBase-R, Ethernet 40GBASE-CR4, Ethernet 100GBase-CR4, Ethernet 40GBase-R2, Ethernet 25GBase-R, Ethernet 50GBase-R2, Ethernet 200GBase-CR4, Ethernet 100GBase-CR2, Ethernet 100GBase-CR1, Ethernet 50GBase-CR | |
| Storage Controller | ||
| Data Transfer Rate | 200 Gbps | |
| Expansion / Connectivity | ||
| Expansion / Connectivity | 2x 200Gb Ethernet - QSFP112 | |
| Miscellaneous | ||
| Compliant Standards | VCCI, CB, FCC, RoHS, ICES, cTUVus, SFI, KC, RCM | |
| Environmental Compliance | Min Operating Temperature: 32 °F | |
| Max Operating Temperature: 131 °F | ||
| Humidity Range Operating: 10 - 85% RH | ||
| If you need Technical Support for this item please contact: | |
| Provider: | Nvidia |
| Type of Support: | FULL |
| Phone No.: | 800-797-6530 |
| URL: | Click here for Manufacturer Website |
