| Main Specifications |
| Device Type | IoT SuperServer |
| Built-in Devices | X13SEW-TF |
| Form Factor | 1U Rackmount - CSE-515B-R801W |
| Dimensions (WxDxH) | Height 1.7" (44.5 mm) x Width 17.2" (436.88 mm) x Depth 16.9" (429.3 mm) |
| Weight | Gross Weight: 15 lbs (6.8 kg) - Net Weight: 10 lbs (4.54 kg) |
| Enclosure Color | Silver |
| Processor |
| Compatible Processors | 5th Gen Intel Xeon / 4th Gen Intel Xeon Scalable processors |
| Compatible Socket | Single Socket E (LGA-4677) |
| Cache/Core | Up to 32C/64T, Up to 60MB Cache |
| System Memory |
| Memory Capacity | Slot Count: 8 DIMM slots, Max Memory (1DPC): Up to 2TB 5600MT/s ECC DDR5 RDIMM |
| Memory Voltage | 1.1V |
| On-Board Devices |
| SATA | SATA (6Gbps), RAID 0/1 support |
| Chipset | Intel C741 |
| Network Connectivity | 2 RJ45 10GbE |
| Input / Output |
| LAN | 1 RJ45 1 GbE Dedicated IPMI LAN port(s), 2 RJ45 10 GbE LAN port(s) (Intel X550-AT2) |
| USB(s) | 2 USB 2.0 Type-A port(s), 2 USB 3.2 Gen1 Type-A port(s) |
| Video Output | 1 VGA port |
| Management |
| Software | SuperCloud Composer, Supermicro Server Manager (SSM), Supermicro Update Manager (SUM), Supermicro SuperDoctor 5 (SD5), Super Diagnostics Offline (SDO), Supermicro Thin-Agent Service (TAS), SuperServer Automation Assistant (SAA) New |
| Power Configurations | Power-on mode for AC power recovery, ACPI Power Management |
| FAN | Fans with tachometer monitoring, Status monitor for speed control, Pulse Width Modulated (PWM) fan connectors |
| Security |
| Hardware | Trusted Platform Module (TPM) 2.0, Silicon Root of Trust (RoT) – NIST 800-193 Compliant |
| Miscellaneous |
| Features | Cryptographically Signed Firmware, Secure Boot, Secure Firmware Updates, Automatic Firmware Recovery, Supply Chain Security: Remote Attestation, Runtime BMC Protections, System Lockdown |
| PC Health Monitoring |
| CPU | Monitors for CPU Cores, Chipset Voltages, Memory |
| Temperature | Monitoring for CPU and chassis environment, CPU thermal trip support, PEPI |
| Front Panel |
| LEDs | LAN1 activity, LAN2 activity, Power status |
| Buttons | Power On/Off button |
| Expansion / Connectivity |
| Expansion Slots Total (Free) | 1 PCIe 5.0 x16 LP slot(s), 2 PCIe 5.0 x16 FHFL slot(s) |
| Expansion Bays Total (Free) | 2 internal fixed 2.5" SATA drive bay(s) |
| M.2 | 1 M.2 PCIe 3.0 x2 NVMe slot(s) (M-key 2280/22110) |
| System Cooling |
| Fans/Air Shroud | 1 Air Shroud(s) |
| 6 heavy duty fans with optimal fan speed control |
| Power Supply |
| Power Supply | 2x 800W Redundant (1 + 1) Platinum Level (94%) power supplies |
| Environmental |
| Operating Environment | Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) |
| Operating Relative Humidity: 8% to 90% (non-condensing) |
| Non-operating Relative Humidity: 5% to 95% (non-condensing) |
| Operating Temperature: 0°C ~ 40°C (32°F ~ 104°F) |
| Parts List - (Items Included) |
| Motherboard / Chassis | 1x MBD-X13SEW-TF/CSE-515B-R801W |
| Cable(s) | 1x CBL-0082L, 2x CBL-0483L, 1x CBL-MCIO-1218M5 OR CBL-MCIO-1218M5-1 |
| Fan(s) | 2x FAN-0167L4 |
| Riser Cards | 1x RSC-W-66G5, 1x RSC-WR-6G5+ |
| Heatsink / Retention | 1x SNK-P0087P |
| Power Supply Number | 2x PWS-804S-1R |
| Power Distributor(s) | 1x PDB-PT514-2824 |
