- Supermicro AS-2115HV-TNRT Workstation UP 2U Barebone Single AMD Ryzen Threadripper PRO 7000 WX-Series Processor
Supermicro AS-2115HV-TNRT Workstation UP 2U Barebone Single AMD Ryzen Threadripper PRO 7000 WX-Series Processor
• Deep Learning/AI/Machine Learning Development
• Cloud Gaming
• Rack Workstation
Barebone 2U Rackmount SuperServer, Support Single Processor, Supporting AMD Ryzen Threadripper PRO 7000 WX-Series Processor (Up to 96-Core/192Thread, Up to 384MB Cache). Max GPU Count: Up to 4 double-width GPUs, Up to 2TB in 8 DIMM slots, RDIMM, Chipset: System on Chip, On-Board: SAS3, Drive Bays: 8x Front Hot-swap 2.5in NVMe/SAS/SATA Drive Bays, 2x M.2 PCIe 4.0 x4 NVMe slots (M-key 22110(default)/2280), Network Connectivity: Via AIOM, 2600W Power Supply - (CSE-HS201-R000NFP + H13SRH) - AS-2115HV-TNRT
1. 2600W Redundant Power Supplies Titanium Level Certified Optional Configuration: 1600W and 2000W Redundant Power Supplies (*Full redundancy based on configuration and application load)
2. AMD Ryzen™ Threadripper™ PRO 7000WX series LGA-4844 up to 350W TDP Processors, CPU and Memory Overclocking supported
3. 8x DDR5 ECC Registered RDIMM/3DS RDIMM, DDR5-5200MHz Up to total 2TB
4. 1 AIOM/OCP NIC 3.0 Slot (Optional parts required for 2nd AIOM slot) Up to 4x PCIe 5.0 x16 (FHFL) slots or 8x PCIe 5.0 x8 (FHFL) slots
5. 8 Hot-swap 2.5" NVMe/SAS/SATA (Optional parts required for NVMe/SAS/SATA configurations)
Extra Specifications for Supermicro AS-2115HV-TNRT Workstation UP 2U Barebone Single AMD Ryzen Threadripper PRO 7000 WX-Series Processor
Product SKUs | ||
Product SKUs | AS -2115HV-TNRT | |
Motherboard | ||
Motherboard | Super H13SRH | |
Processor | ||
CPU | Single processor(s) | |
AMD Ryzen™ Threadripper™ PRO 7000 WX-Series | ||
Core Count | Up to 96C/192T; Up to 384MB Cache | |
Note | Supports up to 350W TDP CPUs (Air Cooled) | |
GPU | ||
Max GPU Count | Up to 4 double-width GPU(s) | |
Supported GPU | View GPU Options | |
NVIDIA PCIe: RTX A6000, RTX 6000 ADA, L40S | ||
CPU-GPU Interconnect | PCIe 5.0 x16 CPU-to-GPU Interconnect | |
GPU-GPU Interconnect | PCIe | |
System Memory | ||
Memory | View Memory Options | |
Slot Count: 8 DIMM slots | ||
Max Memory (1DPC): Up to 2TB 5600MT/s ECC DDR5 RDIMM | ||
On-Board Devices | ||
Chipset | System on Chip | |
Network Connectivity | Via AIOM | |
View AOC Options | ||
View AIOM Options | ||
IPMI | Support for Intelligent Platform Management Interface v.2.0 | |
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support | ||
Input / Output | ||
LAN | 1 RJ45 1 GbE Dedicated IPMI LAN port(s) | |
USB | 2 USB 3.0 port(s) (rear) | |
Video | 1 VGA port(s) | |
System BIOS | ||
BIOS Type | AMI 256MB SPI Flash | |
BIOS Features | SMBIOS 3.5 or later | |
UEFI 2.9 | ||
ACPI 6.5 SMBIOS 3.6 or later UEFI 2.8 Plug and Play (PnP) USB Keyboard support | ||
Management | ||
Software | KVM with dedicated LAN | |
Redfish API | ||
SuperDoctor® 5 | ||
IPMI 2.0 | ||
Supermicro Update Manager (SUM) | ||
Supermicro Server Manager (SSM) | ||
Super Diagnostics Offline | ||
Power configurations | ACPI Power Management | |
Power-on mode control for AC power loss recovery | ||
Power button override mechanism, | ||
Security | ||
Hardware | Trusted Platform Module (TPM) 2.0 | |
Silicon Root of Trust (RoT) – NIST 800-193 Compliant | ||
Features | Cryptographically Signed Firmware | |
Secure Boot | ||
Secure Firmware Updates | ||
Automatic Firmware Recovery | ||
Supply Chain Security: Remote Attestation | ||
Runtime BMC Protections | ||
System Lockdown | ||
PC Health Monitoring | ||
FAN | Status monitor for speed control | |
Pulse Width Modulated (PWM) fan connectors | ||
Fans with tachometer monitoring | ||
Temperature | Monitoring for CPU and chassis environment | |
Thermal Control for fan connectors | ||
Voltage | System temperature, Memory temperature, CPU temperature, 3.3V standby, +5V standby, +5V, +3.3V, +12V, CPU thermal trip support | |
Chassis | ||
Form Factor | 2U Rackmount | |
Model | CSE-HS201-R000NFP | |
Dimensions and Weight | ||
Height | 3.5" (88.9 mm) | |
Width | 17.2" (437 mm) | |
Depth | 31.74" (806.2 mm) | |
Package | 9.96" (H) x 26.46" (W) x 43.31" (D) | |
Weight | Gross Weight: 75 lbs (34 kg) | |
Net Weight: 45 lbs (20.5 kg) | ||
Available Color | Silver | |
Front Panel | ||
LED | LAN1 activity | |
HDD activity | ||
Power | ||
System information | ||
Buttons | UID button | |
Power On/Off | ||
Expansion Slots | ||
PCI-Express (PCIe) Configuration | ||
M.2 | ||
Drive Bays / Storage | ||
Drive Bays Configuration | View Drive Options | |
Default: Total 8 bay(s) 8 front hot-swap 2.5" NVMe*/SAS*/SATA* drive bay(s) | ||
8 front hot-swap 2.5" NVMe*/SAS*/SATA* drive bay(s) | ||
(*NVMe/SAS/SATA support may require additional storage controller and/or cables, please see the optional parts list for details) | ||
M.2 | View M.2 Options | |
2 M.2 PCIe 4.0 x4 NVMe slot(s) (M-key 22110(default)/2280) | ||
System Cooling | ||
Fans | 6x 6cm heavy duty fans with optimal fan speed control | |
Air Shroud | 1 Air Shroud(s) | |
Power Supply | ||
Dimension (WxHxL) | 73.5 x 40 x 265 mm | |
+12V | Max: 216A / Min: 0A (200Vac-240Vac) | |
12V SB | Max: 3.5A | |
AC Input | 2600W: 200-240Vac / 50-60Hz | |
2600W: 200-240Vdc / 50-60Hz (for CQC only) | ||
Output Type | Backplanes (gold finger) | |
Operating Environment | ||
ROHS | RoHS Compliant | |
Environmental Spec. | Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) | |
Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) | ||
Operating Relative Humidity: 8% to 90% (non-condensing) | ||
Non-operating Relative Humidity: 5% to 95% (non-condensing) |
Name | Part Number | Price | Add to Cart | Qty. | Description | |
---|---|---|---|---|---|---|
2nd AIOM | MCP-120-20123-0N | 1 | 2nd AIOM cage for AOM-AIOM-2X8 on CSE-HS 201 | |||
2nd AIOM | AOM-AIOM-2X8-G5-P | 1 | AIOM adaptor board (cable solution), PCIe Gen-5,RoHS | |||
2nd AIOM | CBL-CDAT-1060-30 | $ 27.50 | 1 | 2x15,PH1.0 to 2x15,PH1.0,28AWG,30CM,1A/pin,RoHS | ||
2nd AIOM | CBL-MCIO-1240M5 | $ 0.00 | 2 | MCIO (x8 to x8), STR+Ptab, 40cm,30AWG,RoHS | ||
4 NVMe + 4 SATA | CBL-CDAT-1062 | $ 20.00 | 1 | PicoBlade 1.25, 1x4 to 1x4,SB,45cm,3x 26AWG" | ||
4 NVMe + 4 SATA | CBL-MCIO-1243S4Y | $ 75.50 | 1 | (MCIO x8 to 2 SlimSAS x4), STR, 43cm, 85Ohm | ||
4 NVMe + 4 SATA | CBL-MCIO-1330M5 | $ 0.00 | 1 | MCIO (x8 to x8), STR, 30cm,G5,32AWG | ||
4 NVMe + 4 SATA | CBL-MCIO-1332M5 | $ 0.00 | 1 | MCIO (x8 to x8), STR, 32cm,G5,32AWG | ||
8 NVMe | CBL-MCIO-1330M5 | $ 0.00 | 2 | MCIO (x8 to x8), STR, 30cm,G5,32AWG | ||
8 NVMe | CBL-MCIO-1326M5 | $ 0.00 | 1 | MCIO (x8 to x8), STR, 26cm,G5,32AWG | ||
8 NVMe | CBL-MCIO-1332M5 | $ 0.00 | 1 | MCIO (x8 to x8), STR, 32cm,G5,32AWG | ||
8 SAS | AOC-S3908L-H8IR-16DD | $ 695.50 | 1 | 8 int 12Gb/s ports, x8 Gen4, ROC - LP, 16 HDD | ||
8 SAS | CBL-CDAT-1062 | $ 20.00 | 1 | PicoBlade 1.25, 1x4 to 1x4,SB,45cm,3x 26AWG | ||
8 SAS | CBL-SAST-1264F-100 | $ 39.50 | 1 | Slimline x8 (STR) to 2x Slimline x4 (STR),FFC,64/64CM | ||
8 SAS | AOC-S3808L-L8IT | $ 397.50 | 1 | 8 int 12Gb/s SAS3 ports, x8 Gen4, HBA - LP,122HDD | ||
8 SATA | CBL-MCIO-1243S4Y | $ 75.50 | 1 | (MCIO x8 to 2 SlimSAS x4), STR, 43cm, 85Ohm | ||
GPU and Riser Power Cables | CBL-PWEX-1364-26 | $ 26.00 | 1 | 12VHPWR 2x6+4S to 2x4,MicroHi,26cm,6.25A/p,16AWG,RoHS | ||
GPU and Riser Power Cables | CBL-PWEX-1172-2654 | $ 0.00 | 1 | McHi,P3.0(2x4 to 2x2)+ to MnFt,2x4,PH4.2,26/54CM,9A/p,16 | ||
GPU and Riser Power Cables | CBL-PWEX-1171-2654 | $ 29.00 | 1 | McHi,P3.0(2x4 to 2x2)+ to MnFt,P4.2,2x (2x3+2x1),26/54cm | ||
GPU and Riser Power Cables | CBL-PWEX-1136YVB-45 | $ 25.00 | 1 | (2x4 to 3 2x2), PH3.0,45cm,8.5A/p,18AWG,RoHS | ||
GPU and Riser Power Cables | CBL-PWEX-1136YB-25 | $ 25.00 | 1 | MicroHi(2x4 to 2x2Y),PH3.0,25/25cm,8.5A/p,18AWG,RoH | ||
PCIe 5.0 x16 (4x double width) | CBL-MCIO-1335M5R | $ 45.00 | 2 | MCIO x8 (RA to STR),35CM,32AWG | ||
PCIe 5.0 x16 (4x double width) | MCP-120-20118-0N | $ 31.00 | 1 | Middle riser support bracket for 2U Intel and AMD CSE-HS201 | ||
PCIe 5.0 x16 (4x double width) | MCP-240-21108-0N | $ 56.50 | 2 | Riser Bracket(2-slot) for RSC-H-68G5 | ||
PCIe 5.0 x16 (4x double width) | MCP-240-21908-0N | $ 70.50 | 1 | Riser Bracket(4-slot) | ||
PCIe 5.0 x16 (4x double width) | RSC-H-68G5 | $ 84.00 | 3 | 1U LHS Hyper Riser card with two PCIe 5.0 slots | ||
PCIe 5.0 x16 (4x double width) | RSC-H-A6G5H | $ 127.50 | 1 | 1U Active LHS Hyper riser card with one PCIe 5.0 slot | ||
PCIe 5.0 x16 (4x double width) | CBL-MCIO-1245M5R | $ 76.50 | 2 | MCIO x8 (RA to STR),45cm,30AWG | ||
PCIe 5.0 x16 (4x double width) | CBL-GNZ4-1227M5YRR16 | $ 82.00 | 1 | (GENZ 4C STR to 2 MCIO) x8 RA/RA 27/16cm | ||
PCIe 5.0 x16 (8x single width) | MCP-120-20118-0N | $ 31.00 | 1 | Middle riser support bracket for 2U Intel/AMD in CSE-HS201 | ||
PCIe 5.0 x16 (8x single width) | RSC-H2-6888G5L | $ 168.00 | 1 | 2U LHS Hyper Riser card with 4 PCIe 5.0 slots | ||
PCIe 5.0 x16 (8x single width) | MCP-240-21908-0N | $ 70.50 | 1 | Riser Bracket(4-slot) | ||
PCIe 5.0 x16 (8x single width) | CBL-GNZ4-1227M5YR21 | $ 0.00 | 1 | (GENZ 4C STR to 2 MCIO) x8 STR/RA 27/21cm | ||
PCIe 5.0 x16 (8x single width) | RSC-H-68G5 | $ 84.00 | 2 | 1U LHS Hyper Riser card with two PCIe 5.0 slots | ||
PCIe 5.0 x16 (8x single width) | MCP-240-21108-0N | $ 56.50 | 2 | Riser Bracket(2-slot) for RSC-H-68G5 | ||
PCIe 5.0 x16 (8x single width) | CBL-MCIO-1245M5R | $ 76.50 | 1 | MCIO x8 (RA to STR),45cm,30AWG | ||
PCIe 5.0 x16 (8x single width) | CBL-MCIO-1245M5-Z | $ 61.00 | 3 | MCIO x8 (STR to STR),45cm,30AWG" | ||
Power Supplies and Cables | CBL-PWCD-0160-IS • | 2 | PWCD,US,NEMA5-15P TO IEC60320 C13,6FT,16AWG,RoHS/REACH | |||
Power Supplies and Cables | CBL-PWCD-0376-IS • | 2 | PWCD,US,IEC60320 C19 TO C20,940mm (3ft),14AWG,15A,250V,Black | |||
Power Supplies and Cables | CBL-PWCD-0565-CT | $ 26.00 | 2 | PWCD, US, IEC60320 C14 TO C19, 6ft, 15A/250V, 14AWG, RoHS | ||
Power Supplies and Cables | CBL-PWCD-0579-1 | $ 23.00 | 2 | PWCD,US,IEC60320 C14 TO C13,6FT,14AWG,RoHS | ||
Power Supplies and Cables | CBL-PWCD-0612JPBK1 | $ 25.00 | 2 | PWCD,JPN,IEC60320 C13 TO C14,6FT,12A/250V,BK,RoHS | ||
Power Supplies and Cables | CBL-PWCD-0925 | $ 26.00 | 2 | PWCD,US,NEMA 5-15P TO IEC60320 C19, 6FT, 14AWG, 15A/125V | ||
Power Supplies and Cables | PWS-2K63A-1R | $ 620.50 | 2 | 1U 2600W redundant power supply 220-264Vac, C19 plug | ||
Power Supplies and Cables | PWS-2K07A-1R | $ 530.50 | 2 | 1U 2000W redundant power supply 90-264Vac | ||
Power Supplies and Cables | PWS-1K63A-1R | $ 438.50 | 2 | 1U 1000W/1600W redundant power supply 90-264Vac |
Warranty: | 3 years labor, 1 year parts, 1 year advance replacement (doa) |
Coverage: | Replacement or repair |
Average Service Time: | Overnight replacement for 1 year, 2 weeks afterward |
