| Main Specifications |
| Device Type | SuperChassis |
| Form Factor | 5U (Full Tower) |
| Supported Mainboard Form Factor | Support for motherboard size ATX 12" x 10", E. ATX 12" x 13" |
| Dimensions (WxDxH) | Height 21.06" (535 mm) x Width 8.74" (222 mm) x Depth 22.56" (573 mm) |
| Weight | Gross Weight 39 lbs (17.74 kg) - Net Weight 20 lbs (14.9 kg) |
| Enclosure Color | Black |
| Port | 2x Audio Jacks |
| 1x USB 3.0 Gen 1-Type-c |
| 2x USB 3.0 Gen 1-Type-A |
| 2x USB 2.0 |
| Processor Support |
| Processor Support | Dual and Single Intel® Xeon® and AMD processors |
| Expansion / Connectivity |
| Expansion Slots Total (Free) | 8x Full-height, Full-length expansion slot(s) |
| Expansion Bays Total (Free) | 4x 3.5" Internal drive bay |
| 2x 2.5" drive bay |
| Peripheral Bay (Free) | 2x standard 5.25" drive bay |
| Front Panel |
| Buttons | Power On/Off button, LED light bar ON/OFF |
| LEDs | Power Status LED |
| Front Bezel | 1x MCP-210-GS701-0B |
| System Cooling |
| Fans/Air Shroud | 2x 12cm front cooling fan(s), 1x 12cm rear exhaust fan(s) |
| System Monitoring |
| System Monitoring | Optional Chassis intrusion switch |
| Environmental |
| Operating Environment | Operating Temperature Range: 5°C - 35°C (41°F - 95°F) |
| Non-Operating Temperature Range: -40°C - 70°C (-40°F - 158°F) |
| Operating Relative Humidity Range: 8% - 90% (non-condensing) |
| Non Operating Relative Humidity Range: 5% - 95% (non-condensing) |
| Power Supply |
| Power Supply | 2000W PS2 Multi-output Power Supply |
| Certification | 80PLUS Platinum Certified |
| Regulatory Safety / EMC | BSMI, CCC, CE/EMC, FCC class B, TUV/CB, UL/CUL |
| Parts List - (Items Included) |
| Parts | 8x MCP-120-00116-0B, 1x MCP-230-GS702-0B, 1x MCP-290-GS701-0N, 1x MCP-290-GS702-0B, 1x MCP-290-GS703-0B, 1x MCP-290-GS704-0B, MCP-290-GS705-0B |
| Fan(s) | 2x FAN-0221L4, 1x FAN-0222L4 |
| Front Panel | 1x MCP-280-GS701-0B |
| Drive Tray(s) | 2x MCP-220-GS701-0N, 4x MCP-220-GS702-0B |
| Power Supply Number | 1x PWS-2K01-PQ |
