| GPU |
| Max GPU Count | Up to 1 double-width or 2 single-width GPUs |
| Supported GPU | View GPU Options |
| NVIDIA PCIe: L40, RTX 6000 Ada Generation, L4, A2 |
| System Memory |
| Memory Voltage | 1.1V |
| Memory | View Memory Options |
| Slot Count: 8 DIMM slots |
| Max Memory (1DPC): Up to 2TB 6400MT/s ECC DDR5 RDIMM |
| On-Board Devices |
| Chipset | System on Chip |
| Network Connectivity | View AOC Options |
| 2 RJ45 10GBASE-T with Intel® X550 |
| 1 RJ45 1GbE with ASPEED AST2600 |
| Input / Output |
| LAN | 1 RJ45 1 GbE Dedicated BMC LAN port |
| 2 RJ45 10 GbE LAN ports (Intel® X550) |
| TPM | 1 TPM header |
| USB | 4 USB 3.2 Gen1 Type-A ports(Front) |
| Video | 1 VGA port(Front) |
| Serial | 1 COM port(Front) |
| System BIOS |
| BIOS Type | AMI 32MB SPI Flash EEPROM |
| Management |
| Software | Supermicro Thin-Agent Service (TAS) |
| Supermicro Server Manager (SSM) |
| Super Diagnostics Offline (SDO) |
| SuperServer Automation Assistant (SAA) New! |
| Supermicro SuperDoctor® 5 (SD5) |
| Power configurations | Power-on mode for AC power recovery |
| ACPI Power Management |
| Security |
| Hardware | Trusted Platform Module (TPM) 2.0 |
| Silicon Root of Trust (RoT) – NIST 800-193 Compliant |
| Features | Cryptographically Signed Firmware |
| Secure Boot |
| Secure Firmware Updates |
| Automatic Firmware Recovery |
| System Lockdown |
| Product SKUs |
| Product SKUs | SYS-E403-14B-FRN2T |
| Motherboard |
| Motherboard | Super X14SBW-TF |
| Processor |
| CPU | Intel® Xeon® 6700/6500 series processors with P-cores or 6700 series processors with E-cores |
| Single Socket E2 (LGA-4710) |
| Core Count | E-cores: Up to 144C/144T; Up to 108MB Cache |
| P-cores: Up to 144C/144T; Up to 108MB Cache |
| Note | Supports up to 300W TDP CPUs (Air Cooled) |
| Chassis |
| Form Factor | Fan-based Embedded |
| Model | CSE-E403BiF-000NDBP2 |
| Dimensions and Weight |
| Height | 4.62" (117.348 mm) |
| Width | 10.5" (266.7 mm) |
| Depth | 16" (406.4 mm) |
| Package | 10.4" (H) x 16.4" (W) x 26" (D) |
| Weight | Gross Weight: 24.5 lbs (10.95 kg) |
| Net Weight: 18.5 lbs (8.16 kg) |
| Available Color | Black |
| Front Panel |
| LED | LAN1 activity |
| LAN2 activity |
| Power status |
| HDD activity |
| System information |
| reset status |
| Buttons | Power On/Off |
| Expansion Slots |
| PCI-Express (PCIe) Configuration |
| Drive Bays / Storage |
| Drive Bays Configuration | View Drive Options |
| View NVMe Options |
| Default: Total 4 bays 2 front hot-swap 2.5" NVMe drive bays 2 internal fixed 2.5" SATA* drive bays |
| 2 front hot-swap 2.5" NVMe drive bays |
| 2 internal fixed 2.5" SATA* drive bays |
| (*SATA support may require additional storage controller and/or cables) |
| M.2 | View M.2 Options |
| 2 M.2 PCIe 5.0 x2 NVMe slots (M-key 2280/22110) |
| System Cooling |
| Fans | 3x 8cm heavy duty fans with optimal fan speed control 80x80x38mm Fan(s) |
| Air Shroud | 1 Air Shroud |
| Operating Environment |
| Environmental Spec. | Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) |
| Operating Relative Humidity: 8% to 90% (non-condensing) |
| Non-operating Relative Humidity: 5% to 95% (non-condensing) |
| Operating Temperature: 0°C to 45°C (32°F to 113°F) |
