  2. Ready to Ship - Supermicro SYS-421GE-NBRT-LCC-G1 GPU 4U Barebone Two Intel Xeon 8570 Processor (Installed) - Includes: 2.3TB of Memory, 8x 3.8TB U.3 NVMe SSD, 2x 1.92TB M.2 NVMe SSD, Network Card: 8x Single 400G NDR/ETH OSFP And 1x NVIDIA BlueField-3 DPU 200Gb/s, GPU: NVIDIA HGX B200 8-GPU
Ready to Ship - Supermicro SYS-421GE-NBRT-LCC-G1 GPU 4U Barebone Two Intel Xeon 8570 Processor (Installed) - Includes: 2.3TB of Memory, 8x 3.8TB U.3 NVMe SSD, 2x 1.92TB M.2 NVMe SSD, Network Card: 8x Single 400G NDR/ETH OSFP And 1x NVIDIA BlueField-3 DPU 200Gb/s, GPU: NVIDIA HGX B200 8-GPU
Ready to Ship - Supermicro SYS-421GE-NBRT-LCC-G1 GPU 4U Barebone Two Intel Xeon 8570 Processor (Installed) - Includes: 2.3TB of Memory, 8x 3.8TB U.3 NVMe SSD, 2x 1.92TB M.2 NVMe SSD, Network Card: 8x Single 400G NDR/ETH OSFP And 1x NVIDIA BlueField-3 DPU 200Gb/s, GPU: NVIDIA HGX B200 8-GPU
Ready to Ship - Supermicro SYS-421GE-NBRT-LCC-G1 GPU 4U Barebone Two Intel Xeon 8570 Processor (Installed) - Includes: 2.3TB of Memory, 8x 3.8TB U.3 NVMe SSD, 2x 1.92TB M.2 NVMe SSD, Network Card: 8x Single 400G NDR/ETH OSFP And 1x NVIDIA BlueField-3 DPU 200Gb/s, GPU: NVIDIA HGX B200 8-GPU
Ready to Ship - Supermicro SYS-421GE-NBRT-LCC-G1 GPU 4U Barebone Two Intel Xeon 8570 Processor (Installed) - Includes: 2.3TB of Memory, 8x 3.8TB U.3 NVMe SSD, 2x 1.92TB M.2 NVMe SSD, Network Card: 8x Single 400G NDR/ETH OSFP And 1x NVIDIA BlueField-3 DPU 200Gb/s, GPU: NVIDIA HGX B200 8-GPU
Ready to Ship - Supermicro SYS-421GE-NBRT-LCC-G1 GPU 4U Barebone Two Intel Xeon 8570 Processor (Installed) - Includes: 2.3TB of Memory, 8x 3.8TB U.3 NVMe SSD, 2x 1.92TB M.2 NVMe SSD, Network Card: 8x Single 400G NDR/ETH OSFP And 1x NVIDIA BlueField-3 DPU 200Gb/s, GPU: NVIDIA HGX B200 8-GPU

Ready to Ship - Supermicro SYS-421GE-NBRT-LCC-G1 GPU 4U Barebone Two Intel Xeon 8570 Processor (Installed) - Includes: 2.3TB of Memory, 8x 3.8TB U.3 NVMe SSD, 2x 1.92TB M.2 NVMe SSD, Network Card: 8x Single 400G NDR/ETH OSFP And 1x NVIDIA BlueField-3 DPU 200Gb/s, GPU: NVIDIA HGX B200 8-GPU

  • NVIDIA HGX B200 8-GPU Installed

  • 8x 3.8TB U.3 NVMe SSD, 2x 1.92TB M.2 NVMe SSD

  • Powered by Intel Xeon Scalable 8570 Processor With 56-Core (2.10GHz)

  • 2.3TB Memory Included to ensure smooth multitasking and efficient performance

Complete Server 4U Rackmount SuperServer, Two Intel Xeon Intel Xeon 8570 Processor (Installed) With 56-Core (2.10GHz). Onboard: NVIDIA HGX B200 8-GPU. Total Memory Installed: 2.3TB DDR5-4800 (Max 32 DIMM up to 8TB), Chipset: System on Chip. Includes: 8x 3.8TB U.3 NVMe Solid-state Drive (SSD), 2x 1.92TB M.2 NVMe Solid-state Drive (SSD). Drive Bays / Storage: 8 Front Hot-swap 2.5in NVMe Drive Bays, 2 M.2 NVMe Slots (M-key). Network Connectivity: 8x Single 400G NDR/ETH OSFP, 1x NVIDIA BlueField-3 DPU 200Gb/s. 4x 6600W Titanium Level Power Supplies - (CSE-GP403TS-R000NFP + X13DEG-D) - SYS-421GE-NBRT-LCC-G1

$ 387,900.00$ 387,900.00387900.0USD

$ 387,900.00

Option not available

InStock
227 lb

    This combination does not exist.

    Add to Cart

    Key Applications


    • Scientific Research

    • Conversational AI

    • Business Intelligence & Analytics

    • Drug Discovery

    • Finance Services and Fraud Detection

    • AI/Deep Learning Training and InferenceLarge Language Model (LLM) and Generative AI

    • High Performance Computing (HPC)

    • Autonomous Vehicle Technologies


    Key Features


    • Complete liquid-cooled rack integration is required for purchase

    • 5th/4th Gen Intel Xeon Scalable processor support

    • 8x NVIDIA SXM B200 GPUs, 1.4TB of GPU memory space

    • 32x DIMM slots, ECC RDIMM DDR5 up to 4TB 5600MT/s

    • 8x PCIe 5.0 x16 LP, 2x PCIe 5.0 x16 FHHL slots

    • 8x front hot-swap 2.5" NVMe U.2, 2x front hot-swap NVMe M.2

    • 2x 10GbE RJ-45, 1x Dedicated BMC/IPMI

    • 4x Redundant 6600W Titanium Level power supplies

    Extra Specifications for Ready to Ship - Supermicro SYS-421GE-NBRT-LCC-G1 GPU 4U Barebone Two Intel Xeon 8570 Processor (Installed) - Includes: 2.3TB of Memory, 8x 3.8TB U.3 NVMe SSD, 2x 1.92TB M.2 NVMe SSD, Network Card: 8x Single 400G NDR/ETH OSFP And 1x NVIDIA BlueField-3 DPU 200Gb/s, GPU: NVIDIA HGX B200 8-GPU

    Main Specifications
    Device TypeGPU SuperServer
    Built-in DevicesSuper X13DEG-D
    GPU SupportNVIDIA HGX B200 8-GPU (Installed)
    Form Factor4U Rackmount - CSE-GP403TS-R000NFP
    Dimensions (WxDxH)Height 6.85" (174 mm) x Width 17.6" (449 mm) x Depth 35.25" (895.35 mm)
    WeightGross Weight: 227 lbs (103 kg) - Net Weight: 191 lbs (87 kg)
    Enclosure ColorSilver
    Processor
    Processor InstalledTwo Intel Xeon Intel Xeon 8570 Processor (Installed) With 56-Core (2.10GHz)
    System Memory
    Memory Installed2.3TB DDR5-4800
    Drive Bays
    Hard Drive Installed8x 3.8TB U.3 NVMe Solid-state Drive (SSD), 2x 1.92TB M.2 NVMe Solid-state Drive (SSD)
    On-Board Devices
    Network Connectivity8x Single 400G NDR/ETH OSFP And 1x NVIDIA BlueField-3 DPU 200Gb/s (Included)
    ChipsetSystem on Chip
    Input / Output
    Video Output1 VGA port
    System BIOS
    BIOS TypeAMI 32MB UEFI
    Management
    SoftwareSuperCloud Composer, Supermicro Server Manager (SSM), Super Diagnostics Offline (SDO), Supermicro Thin-Agent Service (TAS), SuperServer Automation Assistant (SAA) New!, Plug-ins for 3rd Party Software
    Power ConfigurationsPower-on mode for AC power recovery, ACPI Power Management
    Security
    HardwareTrusted Platform Module (TPM) 2.0
    PC Health Monitoring
    CPUMonitors for CPU Cores, Chipset Voltages, Memory, 8+4 Phase-switching voltage regulator
    FAN6 Fans with tachometer monitoring, Status monitor for speed control, Pulse Width Modulated (PWM) fan connectors
    TemperatureMonitoring for CPU and chassis environment, Thermal Control for fan connectors
    Front Panel
    LEDsNetwork activity LEDs, System information (overheat/UID), UID
    ButtonsPower On/Off, UID/ Reset button
    Expansion / Connectivity
    Expansion Slots Total (Free)Default: 8 PCIe 5.0 x16 LP slots, 2 PCIe 5.0 x16 FHHL slots
    M.22 M.2 NVMe slots (M-key)
    Drive Bays / Storage
    Drive Bays ConfigurationDefault: 8 front hot-swap 2.5" NVMe drive bays
    System Cooling
    Fans/Air ShroudLiquid Cooling: Direct to Chip (D2C) Cold Plate
    5 Fan 60mm Fan(s)
    Power Supply
    Power Supply4x 6600W Titanium Level Power Supplies
    Environmental
    Operating EnvironmentOperating Relative Humidity: 8% to 90% (non-condensing)
    Non-operating Relative Humidity: 5% to 95% (non-condensing)
    Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
    Operating Temperature: 10°C to 35°C (50°F to 95°F)

    Warranty:3 years labor, 1 year parts, 1 year advance replacement (doa)
    Coverage:Replacement or repair
    Average Service Time:1-2 weeks
    E-mail:returnservices@wiredzone.com

    If you need Technical Support for this item please contact:

    Provider:Supermicro
    Type of Support:FULL
    Phone No.:408-503-8000
    URL:Click here for Manufacturer Website
