Supermicro AS-2115HE-TNR Hyper 2U Barebone Single AMD EPYC 9004/9005 Series Processors
Supports Single AMD EPYC 9004/9005 processors series
Dual redundant 2000W Titanium Level hot-plug power supplies
Flexible connectivity with up to 2 PCIe 5.0 x16 OCP 3.0 compatible AIOM slots
Up to 3 double-width PCIe GPU accelerator cards for AI, ML, and HPC workloads
Barebone 2U Rackmount SuperServer For 3D Design And Content Creation, Supports Single Socket SP5 For AMD EPYC 9004/9005 Series Processors (AMD EPYC 9005 series drop-in support requires board revision 2.x). Up to 6TB 4400MT/s ECC DDR5 RDIMM In 24 DIMM Slots. (MBD-H13SSH + CSE-HE211) - AS-2115HE-TNR
1. Single AMD EPYC 9004/9005 CPU, up to 400W (EPYC 9005 needs board rev 2.x)
2. Supports up to 3 double-width PCIe GPU cards
3. Up to 24 DIMMs: 3TB–6TB DDR5 (various speeds/configs)
4. Flexible networking: 2 PCIe 5.0 x16 OCP 3.0 AIOM slots
5. Optional PCIe: up to 5x PCIe 5.0 x8 + 3x PCIe 4.0 x8, or 3x PCIe 5.0 x16 + 1x PCIe 4.0 x16 (GPU/accelerator support)
6. 6 front hot-swap 2.5" NVMe bays
7. Redundant 2000W Titanium hot-plug PSUs
8. 2U rackmount, 22.6" (574mm) depth
Extra Specifications for Supermicro AS-2115HE-TNR Hyper 2U Barebone Single AMD EPYC 9004/9005 Series Processors
| Main Specifications | ||
| Device Type | A+ Server | |
| Built-in Devices | H13SSH-E | |
| Form Factor | 2U Rackmount - CSE-HE211-R000NFP-A | |
| Dimensions (WxDxH) | Height 3.5" (88.9 mm) x Width 17.2" (436.88 mm) x Depth 22.6" (574 mm) | |
| Weight | Gross Weight: 47.4 lbs (21.5 kg) - Net Weight: 34.4 lbs (15.6 kg) | |
| Enclosure Color | Silver | |
| Processor | ||
| Compatible Processors | AMD EPYC 9005/9004 Series Processors | |
| Compatible Socket | Single processor, Supports up to 400W TDP CPUs | |
| Number of Cores | Up to 192C/384T | |
| GPU | ||
| Max GPU Count | Up to 3 double-width or 4 single-width GPUs | |
| CPU-GPU Interconnect | PCIe Gen5 x16 | |
| GPU-GPU Interconnect | PCIe | |
| System Memory | ||
| Memory Capacity | Max Memory (1DPC): Up to 3TB 4800MT/s ECC DDR5 RDIMM (AMD EPYC 9004 Series Processor) | |
| Max Memory (2DPC): Up to 6TB 4000MT/s ECC DDR5 RDIMM (AMD EPYC 9004 Series Processor) | ||
| Slot Count: 24 DIMM slots/12 Channels | ||
| Max Memory (1DPC): Up to 3TB 5200MT/s ECC DDR5 RDIMM (AMD EPYC 9005 Series Processor) | ||
| Max Memory (1DPC): Up to 3TB 5200MT/s ECC DDR5 RDIMM (AMD EPYC 9005 Series Processor) | ||
| Memory Voltage | 1.1V | |
| On-Board Devices | ||
| Chipset | System on Chip | |
| Network Connectivity | Via AIOM | |
| Input / Output | ||
| LAN | 1 RJ45 1 GbE Dedicated BMC LAN port(s) | |
| USB(s) | 2 USB 3.0 Type-A ports(Front) | |
| Video Output | 1 VGA port | |
| System BIOS | ||
| BIOS Type | AMI 32MB SPI Flash EEPROM | |
| BIOS Features | ACPI 6.4, Plug and Play (PnP), SMBIOS 3.5 or later, UEFI 2.8, USB Keyboard support | |
| Management | ||
| Software | SuperCloud Composer, Supermicro Server Manager (SSM), Supermicro Update Manager (SUM), Supermicro SuperDoctor 5 (SD5), Super Diagnostics Offline (SDO), Supermicro Thin-Agent Service (TAS), OOB Management Package (SFT-OOB-LIC ), SuperServer Automation Assistant (SAA) New! | |
| Power Configurations | ACPI Power Management, Power-on mode control for AC power loss recovery, Power button override mechanism | |
| Security | ||
| Hardware | Trusted Platform Module (TPM) 2.0, Silicon Root of Trust (RoT) – NIST 800-193 Compliant | |
| Features | Cryptographically Signed Firmware, Secure Boot, Secure Firmware Updates, Automatic Firmware Recovery, Supply Chain Security: Remote Attestation, Runtime BMC Protections, System Lockdown | |
| PC Health Monitoring | ||
| FAN | Fans with tachometer monitoring, Status monitor for speed control, Pulse Width Modulated (PWM) fan connectors | |
| Temperature | Monitoring for CPU and chassis environment Thermal Control for fan connectors | |
| Voltage | System temperature, Memory temperature, CPU temperature, 3.3V standby, +5V standby, +5V, +3.3V, +12V, CPU thermal trip support | |
| Front Panel | ||
| LEDs | HDD activity LED, LAN1 activity, LAN2 activity, Power Fail, Power status LED, System information | |
| Buttons | Power On/Off, UID button | |
| Expansion Slots | ||
| PCI-Express (PCIe) Configuration | Option A: 2 PCIe 5.0 x16 (in x16) AIOM slots (OCP 3.0 compatible), 3 PCIe 5.0 x16 (in x16) FHFL slots, 2 PCIe 4.0 x8 (in x16) FHFL slots | |
| Option B: 2 PCIe 5.0 x16 (in x16) AIOM slots (OCP 3.0 compatible), 3 PCIe 5.0 x16 (in x16) FHFL slots, 1 PCIe 4.0 x16 (in x16) FHFL slot | ||
| Option C: 2 PCIe 5.0 x16 (in x16) AIOM slots (OCP 3.0 compatible), 5 PCIe 5.0 x8 (in x16) FHFL slots, 3 PCIe 4.0 x8 (in x16) FHFL slots | ||
| PCI | 8 PCI 5V 32-bit slots | |
| Expansion / Connectivity | ||
| M.2 | 1 M.2 PCIe 3.0 x4 slot (M-key 22110(default)/2280), 1 M.2 PCIe 3.0 x2 slot (M-key 22110(default)/2280) | |
| Drive Bays / Storage | ||
| Drive Bays Configuration | 6 rear hot-swap 2.5" PCIe 5.0 x4 NVMe drive bays | |
| 1 M.2 PCIe 3.0 x4 NVMe slot (M-key 22110(default)/2280) | ||
| 1 M.2 PCIe 3.0 x2 NVMe slot (M-key 22110(default)/2280) | ||
| System Cooling | ||
| Fans/Air Shroud | 1 Air Shroud | |
| Up to 6x 6cm heavy duty fans with optimal fan speed control | ||
| Power Supply | ||
| Power Supply | 2x 2000W Redundant (1 + 1) Titanium Level (96%) Hot-plug power supplies | |
| Environmental | ||
| Operating Environment | Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) | |
| Operating Relative Humidity: 8% to 90% (non-condensing) | ||
| Non-operating Relative Humidity: 5% to 95% (non-condensing) | ||
| Operating Temperature: 10°C to 35°C (50°F to 95°F) | ||
| Warranty: | 3 years labor, 1 year parts, 1 year advance replacement (doa) |
| Coverage: | Replacement or repair |
| Average Service Time: | Overnight replacement for 1 year, 2 weeks afterward |
