- Supermicro SYS-122H-TN Hyper 1U Barebone Dual Intel Xeon 6700/6500 Series Processors With P-cores Or 6700 Series Processors With E-cores
Supermicro SYS-122H-TN Hyper 1U Barebone Dual Intel Xeon 6700/6500 Series Processors With P-cores Or 6700 Series Processors With E-cores
• Virtualization
• Software-defined Storage
• High Performance Computing
• Cloud Computing
• Enterprise Server
Barebone 1U Rackmount SuperServer, Supports Dual Socket E2 (LGA-4710), For Intel Xeon 6700/6500 Series Processors With P-cores Or 6700 Series Processors With E-cores. P-cores: Up to 86C/172T, Up to 336MB Cache per CPU. E-cores: Up to 144C/144T, Up to 108MB Cache per CPU. Supports up to 350W TDP CPUs (Air Cooled / Liquid Cooled). Max GPU Count: Up To 1 Double-width Or 3 Single-width GPUs. 32 DIMM Slots Supporting Up To 8TB Of Memory. Chipset: System on Chip, On-Board: NVMe. Drive Bays / Storage: 8 Front Hot-swap 2.5in NVMe/SAS/SATA Drive Bays, 2 M.2 PCIe 5.0 x2 NVMe Slots (M-key 2280/22110). Network Connectivity: Via AIOM. Others: 1 RJ45 1 GbE Dedicated BMC LAN Port, 3 USB Ports, 1 VGA Port. Optional Configuration For Power Supply - (CSE-HS119-R000NP2 + Super X14DBM-SP) - SYS-122H-TN
1. Intel® Xeon® 6700/6500 series processors with P-cores or 6700 series processors with E-cores
2. 32 DIMM slots supporting up to 8TB of memory
3. 3 PCIe 5.0 x16 slots with support for Network/Storage/GPU/Accelerator cards
4. Flexible networking options with 1 AIOM networking slot (OCP NIC 3.0 compatible)
5. 8x 2.5" hot-swap NVMe/SATA/SAS drive bays; Optional 4x 2.5" hot-swap NVMe/SAS/SATA drive bays; 2x internal M.2 NVMe drive slots; Optional RAID support via storage add-on card
Extra Specifications for Supermicro SYS-122H-TN Hyper 1U Barebone Dual Intel Xeon 6700/6500 Series Processors With P-cores Or 6700 Series Processors With E-cores
| Product SKUs | ||
| Product SKUs | SYS-122H-TN | |
| Motherboard | ||
| Motherboard | Super X14DBM-SP | |
| Processor | ||
| CPU | Dual Socket E2 (LGA-4710) | |
| Intel® Xeon® 6700/6500 series processors with P-cores or 6700 series processors with E-cores | ||
| Core Count | E-cores: Up to 144C/144T; Up to 108MB Cache per CPU | |
| P-cores: Up to 86C/172T; Up to 336MB Cache per CPU | ||
| Note | Supports up to 350W TDP CPUs (Liquid Cooled) | |
| Supports up to 350W TDP CPUs (Air Cooled)* | ||
| *Air Cooled CPUs with TDP over 250W only supported under specific conditions. Contact a Supermicro representative for details. | ||
| GPU | ||
| Max GPU Count | Up to 1 double-width or 3 single-width GPUs | |
| System Memory | ||
| Memory | View Memory Options | |
| Slot Count: 32 DIMM slots | ||
| Max Memory (1DPC): Up to 4TB 6400MT/s ECC DDR5 RDIMM | ||
| Max Memory (1DPC): Up to 1TB 8000MT/s ECC DDR5 MRDIMM (P-core only) | ||
| Max Memory (2DPC): Up to 8TB 5200MT/s ECC DDR5 RDIMM | ||
| Memory Voltage | 1.1V | |
| On-Board Devices | ||
| NVMe | View NVMe Options | |
| NVMe; RAID 0/1/5/10 support(Intel® VROC RAID key required) | ||
| Chipset | System on Chip | |
| Network Connectivity | Via AIOM | |
| View AOC Options | ||
| View AIOM Options | ||
| Input / Output | ||
| LAN | 1 RJ45 1 GbE Dedicated BMC LAN port | |
| USB | 2 USB 3.0 ports(rear) | |
| 1 USB 3.0 port(front) | ||
| Video | 1 VGA port | |
| System BIOS | ||
| BIOS Type | AMI 64MB SPI Flash | |
| Management | ||
| Software | Supermicro Thin-Agent Service (TAS) | |
| Supermicro Server Manager (SSM) | ||
| SuperCloud Composer® | ||
| Super Diagnostics Offline (SDO) | ||
| SuperServer Automation Assistant (SAA) New! | ||
| Power configurations | Power-on mode for AC power recovery | |
| ACPI Power Management | ||
| Security | ||
| Hardware | Trusted Platform Module (TPM) 2.0 | |
| Silicon Root of Trust (RoT) – NIST 800-193 Compliant | ||
| Features | Cryptographically Signed Firmware | |
| Secure Boot | ||
| Secure Firmware Updates | ||
| Automatic Firmware Recovery | ||
| Supply Chain Security: Remote Attestation | ||
| Runtime BMC Protections | ||
| System Lockdown | ||
| PC Health Monitoring | ||
| CPU | Monitors for CPU Cores, Chipset Voltages, Memory | |
| FAN | Status monitor for speed control | |
| Pulse Width Modulated (PWM) fan connectors | ||
| Fans with tachometer monitoring | ||
| Temperature | Monitoring for CPU and chassis environment | |
| Thermal Control for fan connectors | ||
| Chassis | ||
| Form Factor | 1U Rackmount | |
| Model | CSE-HS119-R000NP2 | |
| Dimensions and Weight | ||
| Height | 1.71" (43.6 mm) | |
| Width | 17.3" (438.4 mm) | |
| Depth | 29.27" (743.38 mm) | |
| Package | 7.99" (H) x 23.82" (W) x 27.4" (D) | |
| Weight | Gross Weight: 41 lbs (18.6 kg) | |
| Net Weight: 18.7 lbs (8.5 kg) | ||
| Available Color | Silver | |
| Front Panel | ||
| LED | LAN1 activity | |
| HDD activity | ||
| Power | ||
| System information | ||
| Buttons | UID button | |
| Power On/Off | ||
| Expansion Slots | ||
| PCI-Express (PCIe) Configuration | ||
| Drive Bays / Storage | ||
| Drive Bays Configuration | View Drive Options | |
| (*NVMe/SAS/SATA support may require additional storage controller and/or cables, please see the optional parts list for details) | ||
| View NVMe Options | ||
| Default: Total 8 bays 8 front hot-swap 2.5" NVMe*/SAS*/SATA* drive bays | ||
| 8 front hot-swap 2.5" NVMe*/SAS*/SATA* drive bays | ||
| Option A: Total 12 bays 12 front hot-swap 2.5" NVMe*/SAS*/SATA* drive bays | ||
| 12 front hot-swap 2.5" NVMe*/SAS*/SATA* drive bays | ||
| M.2 | View M.2 Options | |
| 2 M.2 PCIe 5.0 x2 NVMe slots (M-key 2280/22110) | ||
| System Cooling | ||
| Fans | 8 counter-rotating 40x40x56mm Fan(s) | |
| Air Shroud | 2 Air Shrouds | |
| Liquid Cooling | Direct to Chip (D2C) Cold Plate (optional) | |
| Operating Environment | ||
| Environmental Spec. | Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) | |
| Operating Relative Humidity: 8% to 90% (non-condensing) | ||
| Non-operating Relative Humidity: 5% to 95% (non-condensing) | ||
| Operating Temperature: 10°C to 35°C (50°F to 95°F) | ||
| Name | Part Number | Price | Add to Cart | Qty. | Description | |
|---|---|---|---|---|---|---|
| Cable Management Arm + Rail Set | MCP-290-00168-0N + MCP-290-11901-0N | 0 | 7.5" cable management arm + 41" long ball-bearing rail set | |||
| Drive Bay Configuration Options | Refer to User's Manual | 0 | 8 & 12 drive bay configuration options for NVMe, SAS, or SATA support | |||
| Front Bezel | MCP-210-11909-0B | $ 46.50 | 1 | Optional front bezel for 1U Hyper | ||
| Global Services & Support | OS4HR3/2/1 | 0 | Gold Level, 3/2/1-year onsite 24x7x4 SLA | |||
| Global Services & Support | SMSAD3/2/1 | 0 | Bronze Level, 3/2/1-year 3BD SLA | |||
| Global Services & Support | OSNBD3/2/1 | 0 | Silver Level, 3/2/1-year onsite NBD SLA | |||
| Power Supply Options & Accessories | PWS-1K24A-1R | $ 340.00 | 0 | 1U 800W/1200W redundant power supply 90-264Vac | ||
| Power Supply Options & Accessories | PWS-1K63A-1R | $ 443.50 | 0 | 1U 1000W/1600W redundant power supply 90-264Vac | ||
| Power Supply Options & Accessories | PWS-2K07A-1R | $ 535.50 | 0 | 1U 2000W redundant power supply 90-264Vac | ||
| Power Supply Options & Accessories | PWS-2K63A-1R | $ 626.00 | 0 | 1U 2600W redundant power supply 220-264Vac, C19 plug | ||
| Power Supply Options & Accessories | MCP-250-00025-0N | $ 22.50 | 0 | Power supply slot cover for Hyper systems | ||
| Power Supply Options & Accessories | CBL-PWCD-0376-IS • | 0 | PWCD,US,IEC60320 C19 TO C20,940mm (3ft),14AWG,15A,250V,Black | |||
| Power Supply Options & Accessories | CBL-PWCD-0578-1 | $ 18.50 | 0 | PWCD,US,IEC60320 C14 TO C13,3FT,14AWG | ||
| Rail Set | MCP-290-11901-0N | $ 116.00 | 1 | 41" ball-bearing rail set for Hyper servers | ||
| Rail Set | MCP-290-11902-0N | $ 117.00 | 1 | 35.25" ball-bearing rail set for Hyper servers | ||
| Rail Set | MCP-290-11903-0N (included in the system ) | 1 | 30.5" ball-bearing rail set for Hyper servers | |||
| Rail Set | MCP-290-21103-0N | $ 111.50 | 1 | 21.65" ball-bearing rail set for Hyper servers | ||
| Software | SFT-DCMS-Single | 1 | DataCenter Management Package (per node license) | |||
| Trusted Platform Module Options | AOM-TPM-9672V-FIPS-O | 1 | AOM-TPM-9672V-FIPS TPM 2.0 support FIPS | |||
| Trusted Platform Module Options | AOM-TPM-9672V-O | 1 | SPI capable vertical TPM 2.0 |
| Warranty: | 3 years labor, 1 year parts, 1 year advance replacement (doa) |
| Coverage: | Replacement or repair |
| Average Service Time: | Overnight replacement for 1 year, 2 weeks afterward |
