- Supermicro SYS-112C-TN cloudDC 1U Barebone Single Intel Xeon 6700/6500 Series Processors With P-cores Or 6700 Series Processors With E-cores
Supermicro SYS-112C-TN cloudDC 1U Barebone Single Intel Xeon 6700/6500 Series Processors With P-cores Or 6700 Series Processors With E-cores
• Virtualization
• HPC
• CDN, Edge Nodes
• Cloud Computing
• Data Center Optimized
• Storage Headnode
Barebone 1U Rackmount SuperServer, Support Single Socket E2 (LGA-4710), For Intel Xeon 6700/6500 Series Processors With P-cores Or 6700 Series Processors With E-cores. Core Count: P-cores: Up to 86C/172T, Up to 336MB Cache, E-cores: Up to 144C/144T, Up to 108MB Cache. Supports Up To 350W TDP CPUs (Air Cooled). Max GPU Count: Up To 2 Single-width GPUs, Supported GPU: NVIDIA PCIe: L4. 16 DIMM Slots Supporting Up To 4TB Of Memory. Chipset: System on Chip, On-Board: NVMe. Drive Bays / Storage: 8 Front Hot-swap 2.5in PCIe 5.0 x4 NVMe/SAS/SATA Drive Bays. 2 M.2 PCIe 5.0 x2 NVMe Slots (M-key 2280 (default) / 22110, Optional Configuration). Network Connectivity: Flexible Via AIOM. 2x 1000W Power Supplies - (CSE-MD101TS-R000NDP + Super X14SBHM) - SYS-112C-TN
1. All-in-one platform for cloud data centers, based on the OCP Data Center Modular Hardware System (DC-MHS) with flexible I/O and storage configurations Based on Modular Scalable DeNsity Optimized HPM Form Factor (M-SDNO) Support DC-SCM module with OpenBMC
2. Single Intel® Xeon® 6700/6500 series processors with P-cores or 6700 series processors with E-cores
3. 16 DIMM slots supporting DDR5 RDIMM(2DPC/1DPC) or MRDIMM(1DPC)
4. Support FH DPU and single slot GPU
5. Flexible networking options with 1 AIOM networking slot (OCP NIC 3.0 compatible).
6. Breeze through high throughput workloads with PCIe 5.0 NVMe drive support
7. Trusted Platform Module (TPM) 2.0 9672 onboard
Extra Specifications for Supermicro SYS-112C-TN cloudDC 1U Barebone Single Intel Xeon 6700/6500 Series Processors With P-cores Or 6700 Series Processors With E-cores
| Product SKUs | ||
| Product SKUs | SYS-112C-TN | |
| Motherboard | ||
| Motherboard | Super X14SBHM | |
| Processor | ||
| CPU | Intel® Xeon® 6700/6500 series processors with P-cores or 6700 series processors with E-cores | |
| Single Socket E2 (LGA-4710) | ||
| Core Count | P-cores: Up to 86C/172T; Up to 336MB Cache | |
| E-cores: Up to 144C/144T; Up to 108MB Cache | ||
| Note | Supports up to 350W TDP CPUs (Air Cooled) | |
| GPU | ||
| Max GPU Count | Up to 2 single-width GPUs | |
| Supported GPU | View GPU Options | |
| NVIDIA PCIe: L4 | ||
| CPU-GPU Interconnect | PCIe 5.0 x16 CPU-to-GPU Interconnect | |
| System Memory | ||
| Memory | View Memory Options | |
| Max Memory (1DPC): Up to 2TB 6400MT/s ECC DDR5 RDIMM | ||
| Max Memory (1DPC): Up to 512GB 8000MT/s ECC DDR5 MRDIMM (P-core only) | ||
| Max Memory (2DPC): Up to 4TB 5200MT/s ECC DDR5 RDIMM | ||
| Slot Count: 16 DIMM slots/8 Channels | ||
| Memory Voltage | 1.1V | |
| On-Board Devices | ||
| NVMe | View NVMe Options | |
| NVMe; RAID 0/1/5/10 support(Intel® VROC RAID key required) | ||
| Chipset | System on Chip | |
| Network Connectivity | Via AIOM | |
| View AOC Options | ||
| View AIOM Options | ||
| Input / Output | ||
| LAN | 1 RJ45 1 GbE Dedicated BMC LAN port (via DC-SCM) | |
| USB | 2 USB 3.2 Gen1 Type-A ports(Rear) (via DC-SCM) | |
| Video | 1 Mini-DP port(Rear) (via DC-SCM) | |
| TPM | 1 TPM header | |
| System BIOS | ||
| BIOS Type | AMI 32MB SPI Flash EEPROM | |
| Management | ||
| Software | Supermicro Thin-Agent Service (TAS) | |
| Supermicro Server Manager (SSM) | ||
| SuperCloud Composer® | ||
| Super Diagnostics Offline (SDO) | ||
| SuperServer Automation Assistant (SAA) New! | ||
| Power configurations | ACPI/APM Power Management | |
| Security | ||
| Hardware | Trusted Platform Module (TPM) 2.0 | |
| Silicon Root of Trust (RoT) – NIST 800-193 Compliant | ||
| Features | Cryptographically Signed Firmware | |
| Secure Boot | ||
| Secure Firmware Updates | ||
| Automatic Firmware Recovery | ||
| Supply Chain Security: Remote Attestation | ||
| Runtime BMC Protections | ||
| System Lockdown | ||
| PC Health Monitoring | ||
| CPU | Monitors for CPU Cores, Chipset Voltages, Memory | |
| FAN | Status monitor for speed control | |
| Pulse Width Modulated (PWM) fan connectors | ||
| Fans with tachometer monitoring | ||
| Temperature | Monitoring for CPU and chassis environment | |
| Thermal Control for fan connectors | ||
| Chassis | ||
| Form Factor | 1U Rackmount | |
| Model | CSE-MD101TS-R000NDP | |
| Dimensions and Weight | ||
| Height | 1.7" (43 mm) | |
| Width | 17.2" (437 mm) | |
| Depth | 29.4" (747 mm) | |
| Package | 8.1" (H) x 23.8" (W) x 40.6" (D) | |
| Weight | Gross Weight: 47 lbs (21.3 kg) | |
| Net Weight: 31 lbs (14.1 kg) | ||
| Available Color | Black | |
| Front Panel | ||
| LED | LAN1 activity | |
| LAN2 activity | ||
| Power status | ||
| HDD activity | ||
| System information | ||
| Power Failed LED | ||
| Buttons | Power On/Off button | |
| UID button | ||
| Expansion Slots | ||
| PCI-Express (PCIe) Configuration | ||
| Drive Bays / Storage | ||
| Drive Bays Configuration | View Drive Options | |
| (*NVMe/SAS/SATA support may require additional storage controller and/or cables, please see the optional parts list for details) | ||
| View NVMe Options | ||
| 4 front hot-swap 2.5" SAS*/SATA* drive bays | ||
| Default: Total 8 bays 8 front hot-swap 2.5" PCIe 5.0 x4 NVMe*/SAS*/SATA* drive bays | ||
| 8 front hot-swap 2.5" PCIe 5.0 x4 NVMe*/SAS*/SATA* drive bays | ||
| Option A: Total 12 bays 8 front hot-swap 2.5" PCIe 5.0 x4 NVMe*/SAS*/SATA* drive bays 4 front hot-swap 2.5" SAS*/SATA* drive bays | ||
| Option B: Total 12 bays 12 front hot-swap 2.5" PCIe 5.0 x4 NVMe*/SAS*/SATA* drive bays | ||
| 12 front hot-swap 2.5" PCIe 5.0 x4 NVMe*/SAS*/SATA* drive bays | ||
| M.2 | View M.2 Options | |
| 2 M.2 PCIe 5.0 x2 NVMe slots (M-key 2280(default)/22110; Optional Configuration) | ||
| System Cooling | ||
| Fans | 8 Counter-Rotating PWM 40x40x56mm Fan(s) | |
| Air Shroud | 1 CPU Air Shroud | |
| 1 M.2 Side Air Shroud | ||
| Operating Environment | ||
| Environmental Spec. | Non-operating Temperature: -30°C to 60°C (-22°F to 140°F) | |
| Operating Relative Humidity: 8% to 80% (non-condensing) | ||
| Non-operating Relative Humidity: 8% to 90% (non-condensing) | ||
| Operating Temperature: 10°C to 35°C (50°F to 95°F) | ||
| Name | Part Number | Price | Add to Cart | Qty. | Description | |
|---|---|---|---|---|---|---|
| CacheVault for Broadcom 3916/3908 | BTR-CVPM05 + MCP-240-00203-0N (For S3908/S3916) | 1 | SuperCap mounting bracket for PCIe location | |||
| CacheVault for Broadcom 3916/3908 | BTR-CVPM05 + MCP-240-21747-0N (For S3908/S3916) | 1 | SuperCap mounting bracket for AIOM location | |||
| Heat Sink Options | SNK-P0087P | $ 74.00 | 1 | 1U Passive CPU Regular Heat Sink | ||
| Heat Sink Options | SNK-P0087V | $ 0.00 | 1 | 1U Passive CPU Vapor Chamber Heat Sink | ||
| Intel VROC RAID Key for NVMe | AOC-VROCSTNMOD | $ 178.00 | 1 | Standard Upgrade module (Intel + 3rd party Vendor SSD); RAID 0/1/10 | ||
| Intel VROC RAID Key for NVMe | AOC-VROCPREMOD | $ 347.50 | 1 | Premium Upgrade module (Intel + 3rd party Vendor SSD); RAID 0/1/10/5 | ||
| NVMe Cable (Drive Bay 0-3) | CBL-MCIO-1257M5REL | 2 | MCIO x8 (RE to LE), 57CM, 85OHM | |||
| NVMe Cable (Drive Bay 4-11) | CBL-MCIO-1330M5L | 4 | MCIO x8 (STR to LE), 30CM, 85OHM | |||
| Optional M.2 Carrier and Cable | AOM-DCM2-BOOT + 1x CBL-NSKS-1240K5-E | 1 | Internal M.2 Carrier (support RAID thru additional VROC module)) | |||
| Software | SFT-DCMS-Single | 1 | DataCenter Management Package (per node license) | |||
| Storage Control Card and Cable(s) | AOC-S3908L-H8iR-16DD + 1x CBL-SAST-1273LP-100 | 1 | Standard LP, 8 internal ports (12Gb/s) PCIe 4.0 x8, 16HDD; RAID 0, 1, 5, 6, 10, 50, 60 | |||
| Storage Control Card and Cable(s) | AOC-S3916L-H16iR-32DD + 1x CBL-SAST-1273LP-100 + 1x CBL-SAST-1262LP-100 | 1 | Standard LP, 16 internal ports (12Gb/s) PCIe 4.0 x8, 32HDD; RAID 0, 1, 5, 6, 10, 50, 60 | |||
| Storage Control Card and Cable(s) (HBA) | AOC-S3808L-L8IT + 1x CBL-SAST-1273LP-100 | 1 | Standard LP, 8 internal ports (12Gb/s) PCIe 4.0 x8, 122HDD; HBA | |||
| Storage Control Card and Cable(s) (HBA) | AOC-S3816L-L16IT + 1x CBL-SAST-1273LP-100 + 1x CBL-SAST-1262LP-100 | 1 | Standard LP, 16 internal ports (12Gb/s) PCIe 4.0 x8, 122HDD; HBA |
| Warranty: | 3 years labor, 1 year parts, 1 year advance replacement (doa) |
| Coverage: | Replacement or repair |
| Average Service Time: | Overnight replacement for 1 year, 2 weeks afterward |
