Supermicro SYS-222HA-TN Hyper 2U Barebone Dual Intel Xeon 6900 Series Processors With P-cores
• Virtualization
• High Performance Computing
• Artificial Intelligence
• Data Analytics
Barebone 2U Rackmount SuperServer, Supports Dual Socket BR (LGA-7529) For Intel Xeon 6900 Series Processors With P-cores, Up To 128C/256T, Up To 504MB Cache Per CPU. Supports up to 500W TDP CPUs (Air Cooled / Liquid Cooled). Max GPU Count: Up To 4 Double-width Or 4 Single-width GPUs, Supported GPU NVIDIA PCIe: H100 NVL, L40S, L4. 24 DIMM Slots Supporting Up To 6TB Of Memory. Chipset: System on Chip, On-Board: NVMe. Drive Bays / Storage: 8 Front Hot-swap 2.5in NVMe/SAS/SATA Drive Bay. 2 M.2 PCIe 5.0 x2 NVMe Slots (M-key 2280/22110). Network Connectivity: Flexible Via AIOM. Optional Configuration For Power Supply - (CSE-HS201-R000NFP + Super X14DBM-AP) - SYS-222HA-TN
1. Dual Intel® Xeon® 6900-Series Processors with P-cores up to 500W
2. Up to 24 DIMMs supporting up to 6TB 6400MT/s DDR5 RDIMM or 6TB 8800MT/s DDR5 MRDIMM
3. Optional PCIe slot configurations up to 8 PCIe 5.0 x8 or 4 PCIe 5.0 x16 slots with support for double-width GPU/Accelerator cards
4. Flexible networking options with up to 2 AIOM networking slots (OCP NIC 3.0 compatible)
5. 8x 2.5" hot-swap NVMe/SATA/SAS drive bays with optional configurations for 16x/24x 2.5" hot-swap NVMe/SAS/SATA drive bays; 2x internal M.2 NVMe drive slots; Optional RAID support via storage add-on card
Extra Specifications for Supermicro SYS-222HA-TN Hyper 2U Barebone Dual Intel Xeon 6900 Series Processors With P-cores
| Product SKUs | ||
| Product SKUs | SYS-222HA-TN | |
| Motherboard | ||
| Motherboard | Super X14DBM-AP | |
| Processor | ||
| CPU | Dual Socket BR (LGA-7529) | |
| Intel® Xeon® 6900 series processors with P-cores | ||
| Core Count | Up to 128C/256T; Up to 504MB Cache per CPU | |
| Note | Supports up to 500W TDP CPUs (Air Cooled) | |
| Supports up to 500W TDP CPUs (Liquid Cooled) | ||
| GPU | ||
| Max GPU Count | Up to 4 double-width or 4 single-width GPUs | |
| CPU-GPU Interconnect | PCIe 5.0 x16 CPU-to-GPU Interconnect | |
| System Memory | ||
| Memory | View Memory Options | |
| Slot Count: 24 DIMM slots | ||
| Max Memory (1DPC): Up to 6TB 6400MT/s ECC DDR5 RDIMM | ||
| Max Memory (1DPC): Up to 6TB 8800MT/s ECC DDR5 MRDIMM | ||
| Memory Voltage | 1.1V | |
| On-Board Devices | ||
| NVMe | View NVMe Options | |
| NVMe; RAID 0/1/5/10 support(Intel® VROC RAID key required) | ||
| Chipset | System on Chip | |
| Network Connectivity | Via AIOM | |
| View AOC Options | ||
| View AIOM Options | ||
| Input / Output | ||
| LAN | 1 RJ45 1 GbE Dedicated BMC LAN port | |
| USB | 2 USB 3.0 ports(rear) | |
| Video | 1 VGA port | |
| System BIOS | ||
| BIOS Type | AMI 64MB SPI Flash | |
| Management | ||
| Software | Supermicro Thin-Agent Service (TAS) | |
| Supermicro Server Manager (SSM) | ||
| SuperCloud Composer® | ||
| Super Diagnostics Offline (SDO) | ||
| SuperServer Automation Assistant (SAA) New! | ||
| Power configurations | Power-on mode for AC power recovery | |
| ACPI Power Management | ||
| Security | ||
| Hardware | Trusted Platform Module (TPM) 2.0 | |
| Silicon Root of Trust (RoT) – NIST 800-193 Compliant | ||
| Features | Cryptographically Signed Firmware | |
| Secure Boot | ||
| Secure Firmware Updates | ||
| Automatic Firmware Recovery | ||
| Supply Chain Security: Remote Attestation | ||
| Runtime BMC Protections | ||
| System Lockdown | ||
| PC Health Monitoring | ||
| CPU | Monitors for CPU Cores, Chipset Voltages, Memory | |
| FAN | Status monitor for speed control | |
| Pulse Width Modulated (PWM) fan connectors | ||
| Fans with tachometer monitoring | ||
| Temperature | Monitoring for CPU and chassis environment | |
| Thermal Control for fan connectors | ||
| Chassis | ||
| Form Factor | 2U Rackmount | |
| Model | CSE-HS201-R000NFP | |
| Dimensions and Weight | ||
| Height | 3.5" (88.9 mm) | |
| Width | 17.2" (437 mm) | |
| Depth | 31.74" (806.2 mm) | |
| Package | 9.96" (H) x 26.46" (W) x 43.31" (D) | |
| Weight | Gross Weight: 75 lbs (34 kg) | |
| Net Weight: 45 lbs (20.5 kg) | ||
| Available Color | Silver | |
| Front Panel | ||
| LED | LAN1 activity | |
| Power status | ||
| HDD activity | ||
| System information | ||
| Buttons | UID button | |
| Power On/Off | ||
| Expansion Slots | ||
| PCI-Express (PCIe) Configuration | ||
| CXL Support | ||
| Drive Bays / Storage | ||
| Drive Bays Configuration | View Drive Options | |
| (*NVMe/SAS/SATA support may require additional storage controller and/or cables, please see the optional parts list for details) | ||
| View NVMe Options | ||
| Default: Total 8 bays 8 front hot-swap 2.5" NVMe*/SAS*/SATA* drive bays | ||
| 8 front hot-swap 2.5" NVMe*/SAS*/SATA* drive bays | ||
| Option A: Total 16 bays 16 front hot-swap 2.5" NVMe*/SAS*/SATA* drive bays | ||
| 16 front hot-swap 2.5" NVMe*/SAS*/SATA* drive bays | ||
| Option B: Total 24 bays 24 front hot-swap 2.5" NVMe*/SAS*/SATA* drive bays | ||
| 24 front hot-swap 2.5" NVMe*/SAS*/SATA* drive bays | ||
| M.2 | View M.2 Options | |
| 2 M.2 PCIe 5.0 x2 NVMe slots (M-key 2280/22110) | ||
| System Cooling | ||
| Fans | 6 counter-rotating 60x60x56mm Fan(s) | |
| Air Shroud | 2 Air Shrouds | |
| Liquid Cooling | Direct to Chip (D2C) Cold Plate (optional) | |
| Operating Environment | ||
| Environmental Spec. | Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) | |
| Operating Relative Humidity: 8% to 90% (non-condensing) | ||
| Non-operating Relative Humidity: 5% to 95% (non-condensing) | ||
| Operating Temperature: 10°C to 35°C (50°F to 95°F) | ||
| Name | Part Number | Price | Add to Cart | Qty. | Description | |
|---|---|---|---|---|---|---|
| 2nd AIOM/OCP NIC 3.0 Slot | Refer to User's Manual | 0 | AIOM slot A2 kit | |||
| Cable Management Arm + Rail Set | MCP-290-00168-0N + MCP-290-11901-0N | 0 | 7.5" cable management arm + 41" long ball-bearing rail set | |||
| Drive Bay Configuration Options | Refer to User's Manual | 0 | 8 & 16 drive bay configuration options for NVMe, SAS, or SATA support | |||
| Drive Tray Label | LBL-0968 | 0 | Pack of 4 "NVMe" labels for hot-swap drive tray | |||
| Global Services & Support | OS4HR3/2/1 | 0 | Gold Level, 3/2/1-year onsite 24x7x4 SLA | |||
| Global Services & Support | OSNBD3/2/1 | 0 | Silver Level, 3/2/1-year onsite NBD SLA | |||
| Global Services & Support | SMSAD3/2/1 | 0 | Bronze Level, 3/2/1-year 3BD SLA | |||
| PCIe Slot Configuration Options | Refer to User's Manual | 0 | PCIe slot configuration options to enable PCIe slots 1-8 | |||
| Rail Set | MCP-290-11901-0N | $ 116.00 | 1 | 41" ball-bearing rail set for Hyper servers | ||
| Rail Set | MCP-290-11902-0N | $ 117.00 | 1 | 35.25" ball-bearing rail set for Hyper servers | ||
| Rail Set | MCP-290-11903-0N (included in the system ) | 1 | 30.5" ball-bearing rail set for Hyper servers | |||
| Software | SFT-DCMS-Single | 1 | DataCenter Management Package (per node license) | |||
| Trusted Platform Module Options | AOM-TPM-9672V-FIPS-O | 1 | AOM-TPM-9672V-FIPS TPM 2.0 support FIPS | |||
| Trusted Platform Module Options | AOM-TPM-9672V-O | 1 | SPI capable vertical TPM 2.0 |
| Warranty: | 3 years labor, 1 year parts, 1 year advance replacement (doa) |
| Coverage: | Replacement or repair |
| Average Service Time: | Overnight replacement for 1 year, 2 weeks afterward |
