| Main Specifications |
| Device Type | Storage Server |
| Form Factor | 4U Rackmount - CSE-SG401U2-R000NDFP |
| Built-in Devices | Super H14SSF |
| Dimensions (WxDxH) | Height 6.9" (176 mm) x Width 17.65" (448.4 mm) x Depth 33.2" (845 mm) |
| Weight | Gross Weight: 236 lbs (107 kg) - Net Weight: 203 lbs (92 kg) |
| Enclosure Color | No Paint |
| Processor |
| Compatible Processors | AMD EPYC 9005 Series Processors |
| Compatible Socket | Single Socket SP5 |
| Core Count | Up to 96C/192T, Up to 256MB Cache |
| Miscellaneous |
| Note | Supports up to 360W TDP CPUs (Air Cooled) |
| System Memory |
| Memory Capacity | Slot Count: 12 DIMM slots, Max Memory (1DPC): Up to 6TB 6400MT/s ECC DDR5 RDIMM |
| Memory Voltage | 1.1V |
| On-Board Devices |
| NVMe. | NVMe; RAID 0/1 support(Native) |
| Chipset | PCIe switch |
| Network Connectivity | 2 RJ45 10GbE with Broadcom BCM57416 |
| IPMI | Support for Intelligent Platform Management Interface v.2.0 |
| IPMI 2.0 with virtual media over LAN and KVM-over-LAN support |
| TPM | 1 TPM Header |
| Input / Output |
| LAN | 1 RJ45 1 GbE Dedicated BMC LAN port (ASPEED AST2600) |
| 2 RJ45 10 GbE LAN ports (Broadcom BCM57416) |
| USB(s) | 2 USB 3.2 Gen1 Type-A ports (front) |
| Video Output | 1 VGA port |
| System BIOS |
| BIOS Type | AMI 64MB SPI Flash EEPROM |
| Management |
| Software | Redfish API, SuperCloud Composer (SCC), Supermicro Server Manager (SSM), Super Diagnostics Offline (SDO), Supermicro Thin-Agent Service (TAS), IPMI (Intelligent Platform Management Interface) v2.0 with KVM support, SuperServer Automation Assistant (SAA) New |
| Power Configurations | Power-on mode for AC power recovery, ACPI Power Management |
| Security |
| Hardware | Trusted Platform Module (TPM) 2.0, Silicon Root of Trust (RoT) – NIST 800-193 Compliant |
| Features | Automatic Firmware Recovery, Cryptographically Signed Firmware, Runtime BMC Protections, Secure Boot, Secure Firmware Updates, Supply Chain Security: Remote Attestation |
| PC Health Monitoring |
| CPU | 8+4 Phase-switching voltage regulator, Monitors for CPU Cores, Chipset Voltages, Memory |
| FAN | Fans with tachometer monitoring, Pulse Width Modulated (PWM) fan connectors, Status monitor for speed control |
| Temperature | Monitoring for CPU and chassis environment, Thermal Control for fan connectors |
| Front Panel |
| Buttons | Power On/Off, UID button |
| LEDs | HDD activity, LAN1 activity, LAN2 activity, Power status, System information |
| Expansion / Connectivity |
| Expansion Slots Total (Free) | 3 PCIe 5.0 x16 FHHL slots |
| M.2 | 2 M.2 NVMe slots (M-key) |
| Drive Bays / Storage |
| Drive Bays Configuration | 4 front hot-swap E1.S PCIe 5.0 x4 NVMe drive bays |
| 160 top-loading hot-swap 2.5" PCIe 4.0 x1 NVMe drive bays |
| System Cooling |
| Fans/Air Shroud | 1 Air Shroud |
| Up to 5 Hot-swappable rear fans with optimal fan speed control 80x80x80mm Fan(s) |
| Up to 6 Hot-swappable rear fans with optimal fan speed control 40x40x56mm Fan(s) |
| Power Supply |
| Power Supply | 2x 2600W Redundant (1 + 1) Titanium Level (96%) Hot-plug power supplies |
| Environmental |
| Operating Environment | Operating Relative Humidity: 8% to 90% (non-condensing) |
| Non-operating Relative Humidity: 5% to 95% (non-condensing) |
| Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) |
| Operating Temperature: 10°C to 35°C (50°F to 95°F) |
