| Main Specifications |
| Device Type | SuperServer - IoT |
| Form Factor | Fanless Embedded - CSE-E102L |
| Dimensions (WxDxH) | Height 3.15" (80 mm) x Width 7.28" (185 mm) x Depth 5.5" (140 mm) |
| Weight | Gross Weight: 4.3 lbs (1.95 kg) - Net Weight: 3.7 lbs (1.68 kg) |
| Enclosure Color | Black |
| Processor |
| Processor Installed | Arm Cortex-A78AE v8.2 64-bit CPU |
| Cache/Core | Up to 8C/8T, Up to 6MB Cache |
| Drive Bays |
| Hard Drive Installed | 1x 256GB M.2 NVMe Solid-state Drive (SSD) |
| System Memory |
| Memory Type | Onboard 16GB LPDDR5X Memory |
| On-Board Devices |
| Chipset | System on Chip |
| Network Connectivity | 1x 10GbE RJ45, 4x 1GbE RJ45 (PoE Optional) |
| Input / Output |
| LAN | 3 RJ45 1 GbE LAN ports (Intel I210-IT), 1 RJ45 10 GbE LAN port (Marvell AQC113), 1 RJ45 1 GbE LAN port (SoC) |
| USB(s) | 1 USB 3.2 Gen2 Type-C port(Front), 3 USB 3.2 Gen2 Type-A ports(Front) |
| Video Output | 1 HDMI 2 port (Front) |
| Serial Port / Header | 2 COM RS232/RS422/RS485 ports(Front) |
| Others | 1 CANBus port, 1 4 DI/4 x DO (terminal block) port |
| Management |
| Power Configurations | +9~36V DC Power Input |
| Front Panel |
| Buttons | Power On/Off button |
| PC Health Monitoring |
| LED | Power status |
| Expansion / Connectivity |
| Expansion Slots Total (Free) | 1 M.2 PCIe 4.0 x4 NVMe slot (M-key 2280 (default)) |
| 1 M.2 PCIe 4.0 x1 slot (E-key 2230 (default), USB 2.0) |
| 1 M.2 slot (B-key 3052(default) / 3042, USB 3.0) |
| M.2 | 1 M.2 PCIe 4.0 x4 NVMe slot (M-key 2280 (default)) |
| Miscellaneous |
| Environmental Compliance | RoHS Compliant |
| Environmental |
| Operating Environment | Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) |
| Operating Relative Humidity: 8% to 80% (non-condensing) |
| Non-operating Relative Humidity: 8% to 90% (non-condensing) |
| Operating Temperature: -25°C to 60°C (-13°F to 140°F) with 0.7 m/s airflow |
