| Main Specifications |
| Device Type | Motherboard |
| Form Factor | Proprietary |
| Dimensions (WxDxH) | 13.4" x 12.29" (34cm x 31.2cm) |
| Processor |
| Cache | Up to 32 Cores, Up to 64 Cores (Board revision 2.x required) |
| Compatible Processors | Single AMD EPYC 7001/7002 series Processor (Board revision 2.x required) |
| Compatible Socket | Socket SP3 |
| System Memory |
| DIMM Sizes | 8GB, 16GB, 32GB, 64GB, 128GB, 256GB* (*Board revision 2.x required) |
| Memory Voltage | 1.2 V |
| Memory Capacity | 16 DIMM slots, Supports up to 2TB Registered ECC DDR4 2666MHz SDRAM in 16 DIMMs, Supports up to 4TB Registered ECC DDR4 3200MHz SDRAM (Board revision 2.x required), 8-channel memory bus |
| Memory Type | DDR4 2666 MHz Registered ECC, 288-pin gold-plated DIMMs, DDR4 3200 MHz Registered ECC, 288-pin gold-plated DIMMs (Board revision 2.x required) |
| Error Detection | Corrects single-bit errors, Detects double-bit errors (using ECC memory) |
| On-Board Devices |
| Chipset | System on Chip |
| IPMI | Support for Intelligent Platform Management Interface v.2.0, IPMI 2.0 with virtual media over LAN and KVM-over-LAN support, ASPEED AST2500 BMC |
| Network Controllers | 1 Realtek RTL8211E PHY (dedicated IPMI), 2x 10GBase-T LAN Ports via Broadcom BCM57416 |
| TPM | 1 TPM 1.2 header |
| NVMe | SATA/NVMe Hybrid: 16 SATA3 / 4 NVMe, NVMe: 12 NVMe |
| Others | 2 SATA DOM power connectors, 1 TPM 2.0 header, |
| Input / Output |
| USB(s) | 7 USB 3.0 ports (4 rear + 2 front + 1 Type A) |
| SATA | SATA3 (6 Gbps) |
| LAN | 1 RJ45 Dedicated IPMI LAN port, 2 RJ45 10GBase-T Ethernet LAN ports |
| Video Output | 1 VGA port |
| Expansion / Connectivity |
| Expansion Slots Total (Free) | 1 PCI-E 3.0 x32 Left Riser Slot |
| 1 PCI-E 3.0 x16 Right Riser Slot |
| M.2 | Form Factor: 2280, 22110 |
| Key: M-key |
| Interface: 2 PCI-E 3.0 x2 |
| System BIOS |
| BIOS Features | Plug and Play (PnP), DMI 2.3, PCI 2.2, ACPI 5.1, USB Keyboard Support, SMBIOS 3.1.1 |
| BIOS Type | AMI 128Mb SPI Flash EEPROM |
| Management |
| Power configurations | ACPI Power Management, Power-on mode control for AC power loss recovery |
| Software | Super Doctor 5, Watch Dog, NMI, SUM, IPMI 2.0, KVM with dedicated LAN |
| PC Health Monitoring |
| CPU | Monitors CPU Core Voltages, +1.8V, +3.3V, +5V, +5V standby, +3.3V standby, CPU switching voltage regulator, Supports system management utility, VBAT |
| FAN | Up to 6-fan status tachometer monitoring, Up to 6 4-pin fan headers, Dual Cooling Zone, Status monitor for speed control, Pulse Width Modulated (PWM) fan connectors |
| LED | CPU / System Overheat LED |
| Other Features | Chassis Intrusion Detection, Chassis Intrusion Header, UID |
| Temperature | Monitoring for CPU and chassis environment, CPU Thermal Trip Support, Thermal control for 6x Fan connectors, I²C Temperature Sensing Logic |
| Environmental Parameters |
| Operating Temperature | Operating Temperature: 10C to 35C (50F to 95F) |
| Operating Relative Humidity: 8% to 90% (non-condensing) |
| Non-operating Relative Humidity: 5% to 95% (non-condensing) |
| Non-operating Temperature:-40C to 70C (-40F to 158F) |
| Chassis Optimized for |
| 2U Chassis | SC213AC8-R1K23WB |
| Parts List |
| I/O Cables | 1x CBL-SAST-0813 |
