| Main Specifications |
| Device Type | Motherboard |
| Form Factor | E-ATX |
| Dimensions (WxDxH) | 12" x 13" (30.48cm x 33.02cm) |
| Processor |
| Compatible Processors | AMD Ryzen Threadripper PRO 5000WX/3000WX Series Processor, Supports CPU TDP up to 280W |
| Compatible Socket | Socket sWRX8/SP3 |
| Number of Cores | Up to 64 Cores |
| System Memory |
| Memory Capacity | 8 DIMM slots, ECC and Non-ECC, buffered and Un-buffered, U-DIMM, R-DIMM, LRDIMM and 3DS R-DIMM Memory, RDIMM up to 2TB, UDIMM up to 256GB, 8-channel memory bus |
| Memory Type | ECC and Non-ECC, buffered and Un-buffered, U-DIMM, R-DIMM, LRDIMM and 3DS R-DIMM Memory, DDR4 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 Mhz |
| DIMM Sizes | 8GB, 16GB, 32GB, 64GB, 128GB, 256GB |
| Memory Voltage | 1.2V |
| Error Detection | Corrects single-bit errors, Detects double-bit errors (using ECC memory) |
| On-Board Devices |
| Chipset | AMD 500-Series 2019 Premium WRX80 Chipsets |
| SATA/SAS | AMD WRX80 controller for 4 SATA3 (6 Gbps) ports, RAID 0,1,5,10 |
| Network Controllers | 10G LAN: Single LAN via Marvell AQC113C 10Gb controller |
| 1GbE LAN: Single LAN via via Intel® i210AT controller (shared with IPMI) |
| IPMI | ASPEED AST2600 |
| Audio | ALC4050H + ALC1220 7.1 Channel HD Audio |
| Graphics | ASPEED AST2600 BMC, VGA connector is dedicated for IPMI |
| VGA | 1 VGA port (dedicated for IPMI) |
| Input / Output |
| SATA | 4 SATA3 (6 Gbps) ports |
| LAN | 1 RJ45 10GBase-T LAN port, 1 RJ45 GbE LAN port (shared with IPMI) |
| USB(s) | 1 USB 3.2 Gen2x2 port (Type C, 20Gbps), 5 USB 3.2 Gen2 ports (4 Type A, 1 Type C header, 10Gbps), 5 USB 3.2 Gen1 ports (3 Type A, 1 via header), 2 USB 2.0 via header |
| Others | 1 COM port (rear), 1 TPM 2.0 header |
| Expansion / Connectivity |
| Expansion Slots Total (Free) | 6 PCI-E 4.0 x16 slots |
| M.2 | Form Factor: 2280, 22110 |
| Key: M-key |
| Interface: 4 PCI-E 4.0 x4 |
| Software RAID 0,1,5,10 support |
| U.2 | Interface: 2 U.2 Sockets, Software RAID 0,1 support |
| System BIOS |
| BIOS Type | AMI 256Mb Flash EEPROM |
| Management |
| Software | Super Doctor 5, Watch Dog, SUM, IPMI, KVM with shared LAN |
| Power Configurations | ACPI Power Management, Power button override mechanism, Keyboard wakeup from S5, S3/S4 |
| PC Health Monitoring |
| CPU | Monitors CPU Core Voltages, +3.3V, +12V, +3.3Vstb, +5Vstb, Vcore, Vmem, Supports system management utility |
| FAN | Up to 10 4-pin fan headers, Status monitor for speed control |
| Temperature | Monitoring for CPU and chassis environment, CPU Thermal Trip Support, I²C Temperature Sensing Logic |
| LED | CPU / System Overheat LED |
| Other Features | Chassis intrusion detection, Chassis intrusion header |
| Environmental |
| Operating Environment | Operating Temperature: 0°C to 50°C (32°F to 122°F) |
| FCC class B |
| Non-operating Temperature:-5°C to 55°C (23°F to 131°F) |
| Parts List |
| I/O Cables | 2x CBL-0044L, 1x CBL-PWEX-0663 |
| I/O Shield | 1x MCP-260-00159-0N/MCP-260-00159-1N |
| CPU-GPU Power Connector Adapter | 1x CBL-PWEX-0663 |
| M.2 Screw and Stand Kit | 1x MCP-410-00020-0N |
