| Main Specifications |
| Device Type | GPU A+ Server |
| Built-in Devices | Super H14DSG-OM |
| Form Factor | 8U Rackmount - CSE-GP807TS-R000NP |
| Dimensions (WxDxH) | Height 13.8" (356 mm) x Width 17.6" (449 mm) x Depth 37.4" (950 mm) |
| Weight | Gross Weight: 302 lbs (137 kg) - Net Weight: 263 lbs (119 kg) |
| Enclosure Color | Silver |
| Processor |
| Processor Installed | 2x AMD EPYC 9575F (128C/3.3GHz) |
| GPU |
| GPU Installed | NVIDIA HGX B300 8-GPU |
| System Memory |
| Memory Installed | 3TB DDR5-6400 |
| Drive Bays |
| Hard Drive Installed | 8x 7.6TB E1.S NVMe Solid-state Drive (SSD) |
| 2x 1.9TB M.2 NVMe Solid-state Drive (SSD) |
| On-Board Devices |
| Network Connectivity | NIC: 8-port 800GbE/XDR800, NIC: 2-port 200GbE/NDR200 |
| Chipset | System on Chip |
| Power Supply |
| Power Supply | Redundant 6600W Titanium Level |
| Input / Output |
| USB(s) | 1 USB 3.0 Type-A port(Front), 1 USB 2.0 Type-A port(Front) |
| Video Output | 1 VGA port, 1 mini-DP port |
| System BIOS |
| BIOS Type | AMI 64MB UEFI |
| Management |
| Software | SuperCloud Composer, Supermicro Server Manager (SSM), Super Diagnostics Offline (SDO), Supermicro Thin-Agent Service (TAS), SuperServer Automation Assistant (SAA) New! |
| Power Configurations | Power-on mode for AC power recovery, ACPI Power Management |
| Security |
| Hardware | Trusted Platform Module (TPM) 2.0, Silicon Root of Trust (RoT) – NIST 800-193 Compliant |
| Miscellaneous |
| Features | Cryptographically Signed Firmware, Secure Boot, Secure Firmware Updates, Automatic Firmware Recovery, Supply Chain Security: Remote Attestation, Runtime BMC Protections, System Lockdown |
| PC Health Monitoring |
| CPU | 8+4 Phase-switching voltage regulator, Monitors for CPU Cores, Chipset Voltages, Memory |
| FAN | Fans with tachometer monitoring, Pulse Width Modulated (PWM) fan connectors, Status monitor for speed control |
| Temperature | Monitoring for CPU and chassis environment, Thermal Control for fan connectors |
| Front Panel |
| Buttons | Power On/Off, UID |
| LEDs | HDD activity, LAN1 activity, LAN2 activity, Power Fail, Power status, System information (overheat/UID) |
| Expansion / Connectivity |
| Expansion Slots Total (Free) | Default: 2 PCIe 5.0 x16 FHHL slots |
| M.2 | 2 M.2 NVMe slots (M-key) |
| Drive Bays / Storage |
| Drive Bays Configuration | 8 front hot-swap E1.S NVMe drive bays |
| System Cooling |
| Fans/Air Shroud | Up to 12 heavy duty fans with optimal fan speed control |
| Environmental |
| Operating Environment | Operating Relative Humidity: 8% to 90% (non-condensing) |
| Non-operating Relative Humidity: 5% to 95% (non-condensing) |
| Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) |
| Operating Temperature: 10°C to 35°C (50°F to 95°F) |
