| Main Specifications |
| Device Type | A+ Server |
| Built-in Devices | Super H13SRD-F |
| Form Factor | 3U Rackmount - CSE-938NH-R2K20BP2 |
| Dimensions (WxDxH) | Height 5.21" (132 mm) x Width 17.26" (438 mm) x Depth 23.2" (589 mm) |
| Weight | Gross Weight: 88 lbs (39.92 kg) - Net Weight: 62.2 lbs (28.21 kg) |
| Enclosure Color | No Paint |
| Processor |
| Processor Installed | 1x AMD EPYC 4565P (16C/4.3GHz) Per Node |
| System Memory |
| Memory Installed | 64GB DDR5-5600 Per Node |
| Drive Bays |
| Hard Drive Installed | 2x 1.92TB U.2 NVMe Solid-state Drive (SSD) Per Node |
| M.2 (per node) | 1 M.2 NVMe slot (M-key 2280/22110) |
| GPU |
| Max GPU Count (per Node) | Up to 1 single-width GPU |
| Supported GPU (per Node) | NVIDIA PCIe: A2, L4, T4 |
| Input / Output |
| NVMe (per Node) | NVMe, (Native) |
| USB (per Node) | 2 USB 2.0 ports, 1 Type-C port(front) |
| TPM ((per Node) | 1 TPM Onboard/port 80 |
| On-Board Devices |
| Network Connectivity (per Node) | 2-port 10GbE/25GbE AOC Per Node |
| Graphics (per Node) | 1 port |
| System BIOS |
| BIOS Type | AMI 32MB SPI Flash EEPROM |
| Management |
| Software | SuperCloud Composer, Supermicro Server Manager (SSM), Supermicro Update Manager (SUM), Supermicro SuperDoctor® 5 (SD5), Super Diagnostics Offline (SDO), Supermicro Thin-Agent Service (TAS), SuperServer Automation Assistant (SAA) New! |
| Power Configurations (per Node) | Power-on mode for AC power recovery, ACPI 6.0 Power Management |
| PC Health Monitoring |
| CPU | 3-Phase-switching voltage regulator with auto-sense from 0.5V-2.3V, Monitors for CPU Cores, +3.3V, +5V, +12V, +3.3V Standby, +5V Standby, VBAT, Memory, Chipset Voltages. |
| FAN | Fan speed control, Dual Cooling Zone |
| Temperature | Monitoring for CPU and chassis environment |
| Front Panel |
| Buttons | Power On/Off button |
| LEDs | 8 Individual Node Status Indicators, Power Failure |
| Expansion Slots |
| Expansion Slots (per node) | 1 PCIe 5.0 x8 (in x16) LP slot, 1 PCIe 5.0 x8 MicroLP slot |
| Expansion / Connectivity |
| Drive Bays / Storage (per Node) | 2 front fixed 3.5"/2.5" NVMe/SAS/SATA drive bays (SAS/SATA support may require additional storage controller and/or cables) |
| System Cooling |
| Fans/Air Shroud | Up to 4 Heavy Duty 8cm Fan(s) |
| 8 Air Shrouds |
| Power Supply |
| Power Supply | 2x 2200W Redundant (1 + 1) Titanium Level (96%) power supplies |
| Environmental |
| Operating Environment | Operating Temperature: 10°C to 35°C (50°F to 95°F) |
| Non-operating Temperature: -30°C to 60°C (-22°F to 140°F) |
| Operating Relative Humidity: 8% to 80% (non-condensing) |
| Non-operating Relative Humidity: 8% to 90% (non-condensing) |
