| Main Specifications |
| Device Type | A+ Server |
| Built-in Devices | Super H13SAE-MF |
| Form Factor | 1U - CSE-514-505 |
| Dimensions (WxDxH) | Height 1.7" (43 mm) x Width 17.2" (437 mm) x Depth 16.9" (429 mm) |
| Weight | Gross Weight: 16 lbs (7.26 kg) |
| Enclosure Color | Silver |
| Processor |
| Processor Installed | 1x AMD EPYC 4564P (16C/4.5GHz) |
| System Memory |
| Memory Installed | 32GB DDR5-5600 |
| Drive Bays |
| Hard Drive Installed | 1x 1.92TB M.2 NVMe Solid-state Drive (SSD) |
| GPU |
| Max GPU Count | Up to 1 single-width GPU |
| Supported GPUs | NVIDIA PCIe: A2, L4, RTX 4000 Ada Generation, RTX A4000 |
| AMD PCIe: Radeon Pro W7500 |
| CPU-GPU Interconnect | PCIe 5.0 x16 CPU-to-GPU Interconnect |
| On-Board Devices |
| SATA/SAS | SATA (6Gbps), RAID 0/1 support |
| Chipset | AMD B650 |
| Network Connectivity | 1x dual 1GbE, 1x dedicated IPMI |
| Audio | Rear Audio |
| TPM | 1 TPM Header |
| Input / Output |
| USB(s) | 3 Type-A ports(Rear), 2 Type-C ports(Rear), 1 Type-C port(Rear) |
| Video Output | 1 VGA port, 1 DisplayPort 1.4 port, 1 HDMI 2 port |
| System BIOS |
| BIOS Type | AMI 32MB SPI Flash |
| Management |
| Software | SuperCloud Composer, Supermicro Server Manager (SSM), Supermicro Update Manager (SUM), Supermicro SuperDoctor® 5 (SD5), Super Diagnostics Offline (SDO), Supermicro Thin-Agent Service (TAS), SuperServer Automation Assistant (SAA) New! |
| Power Configurations | ACPI 6.0 Power Management |
| Security |
| Hardware | Trusted Platform Module (TPM) 2.0, Silicon Root of Trust (RoT) – NIST 800-193 Compliant |
| Features | Supply Chain Security: Remote Attestation, Runtime BMC Protections |
| PC Health Monitoring |
| FAN | Status monitor for speed control |
| Other Features | 8-pin 12v DC power connector, ACPI power management, ATX Power connector, Chassis intrusion header, Control of power-on for recovery from AC power loss, CPU thermal trip support for processor |
| Temperature | CPU thermal trip support, Monitoring for CPU and chassis environment, PECI |
| Voltage | +1.0V PCH, +1.8V PCH, +12V, +3.3V, +5V, +5V standby, 1.05 (PCH), 3.3V standby, 5 (4-pin), CPU, CPU temperature, CPU thermal trip support, PCH temperature, System temperature, VBAT, VRM |
| Front Panel |
| Buttons | Power On/Off button, System Reset button |
| LEDs | Fan Fail/System Over Heat LED, HDD activity LED, Network Activity LEDs, Power status LED |
| Expansion / Connectivity |
| Expansion Slots Total (Free) | 1 PCIe 5.0 x16 FHHL slot |
| M.2 | 2 M.2 PCIe 5.0 x4 NVMe slots (M-key 2280/22110) |
| Drive Bays / Storage |
| Drive Bays Configuration | Default: 1 internal fixed 3.5" SATA drive bay |
| Option A: 4 internal fixed 2.5" SATA drive bays (SATA support may require additional storage controller and/or cables) |
| System Cooling |
| Fans/Air Shroud | 1 Air Shroud |
| Up to 6x 40mm Fan(s) |
| Power Supply |
| Power Supply | 1x 500W Platinum Level (93%) power supply |
| Environmental |
| Operating Environment | Operating Relative Humidity: 8% to 90% (non-condensing) |
| Non-operating Relative Humidity: 5% to 95% (non-condensing) |
| Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) |
| Operating Temperature: 10°C to 35°C (50°F to 95°F) |
