| Main Specifications |
| Device Type | Motherboard |
| Form Factor | Proprietary |
| Dimensions (WxDxH) | 17" x 15.96" (43.18cm x 40.54cm) |
| Processor |
| Compatible Processors | AMD EPYC 9005/9004 Series Processors |
| Compatible Socket | Dual Socket SP5 |
| Core Count | Up to 384C/768T |
| Note | Supports up to 500W TDP CPUs |
| System Memory |
| Memory Capacity | Slot Count: 24 DIMM slots |
| Max Memory (1DPC): Up to 6TB 6400MT/s ECC DDR5 RDIMM (AMD EPYC™ 9005 Series Processor) |
| Max Memory (1DPC): Up to 6TB 4800MT/s ECC DDR5 RDIMM (AMD EPYC™ 9004 Series Processor) |
| DIMM Sizes | RDIMM:16GB, 24GB, 32GB, 48GB, 64GB, 96GB, 128GB, 256GB |
| Memory Voltage | 1.1V |
| Error Detection | Corrects single-bit errors, Detects double-bit errors (using ECC memory) |
| On-Board Devices |
| IPMI | ASPEED AST2600 BMC |
| TPM | 1 TPM Header |
| Others | 2 SlimSAS (x4) port(s), 1 MCIO port(s), 12 MCIO (PCIe 5.0 x8) port(s) |
| Input / Output |
| USB(s) | 1 USB 2.0 port(s) (Header) |
| System BIOS |
| BIOS Type | AMI 64MB SPI Flash EEPROM |
| BIOS Features | UEFI 2.8, ACPI 6.5, SMBIOS 3.7 or later |
| Management |
| Software | SuperCloud Composer, Supermicro Server Manager (SSM), Super Diagnostics Offline (SDO), Supermicro Thin-Agent Service (TAS), SuperServer Automation Assistant (SAA) New, Plug-ins for 3rd Party Software |
| Security |
| Hardware | Trusted Platform Module (TPM) 2.0 |
| PC Health Monitoring |
| Voltage | +12V,+3.3V,+3.3V standby,CPU thermal trip support,VBAT |
| LED | BMC/IPMI Heartbeat LED, CPU/system overheat LED, Power LED, UID/remote UID LED |
| Temperature | CPU temperature, Memory temperature, VRM temperature |
| FAN | 4x 6-pin fan headers (up to 4 fans) |
| Other Features | RoT |
