| Main Specifications |
| Device Type | Motherboard |
| Form Factor | Micro-ATX |
| Dimensions (WxDxH) | 9.6" x 9.6" (24.38cm x 24.38cm) |
| Processor |
| Compatible Processors | Intel Core Ultra 9/7/5 (Series 2) processors |
| Compatible Socket | Single Socket V1 (LGA-1851) |
| Core Count | Up to 24C |
| Note | Supports up to 125W TDP CPUs |
| System Memory |
| Memory Capacity | Slot Count: 4 DIMM Slots |
| Max Memory (2DPC): Up to 256GB 5600MT/s ECC/non-ECC DDR5 UDIMM |
| DIMM Sizes | UDIMM:8GB, 16GB, 24GB, 32GB, 48GB, 64GB |
| Memory Voltage | 1.1V |
| Error Detection | Corrects single-bit errors, Detects double-bit errors (using ECC memory) |
| On-Board Devices |
| Chipset | Intel W880 |
| SATA/SAS | 4 SATA (6Gbps), RAID 0/1/5/10 support |
| TPM | 1 TPM header, 1 TPM 2.0 onboard |
| Input / Output |
| LAN | 1 RJ45 1 GbE Dedicated IPMI LAN port(s) (ASPEED AST2600 BMC) |
| 2 RJ45 2.5 GbE LAN port(s) (Intel I226LM Ethernet Controller) |
| USB(s) | 2 USB 3.2 Gen2 port(s) (Header), 4 USB 2 port(s) (Header) |
| Video Output | 1 VGA port(s), 2 HDMI port(s), 2 Display Port port(s) |
| Serial Port / Headers | 2 COM port(s) (header) |
| Expansion / Connectivity |
| Expansion Slots Total (Free) | 1 PCIe 5.0 x16 slot(s) |
| 2 PCIe 4.0 x4 slots |
| 1 PCIe 4.0 x8 via MCIO Connector slot |
| M.2 | 1 M.2 PCIe 5.0 x4 slot (M-key 2280/22110) |
| System BIOS |
| BIOS Type | AMI 32MB UEFI |
| BIOS Features | ACPI 6.5, SMBIOS 3.7 or later, UEFI 2.9 |
| Security |
| Hardware | Trusted Platform Module (TPM) 2.0 |
| PC Health Monitoring |
| Voltage | +1.35V,+1.5V,+1.8V,+12V,+3.3V,+5V,+5V standby,1.05 (PCH),6 fans with tachometer status monitoring,BMC/IPMI Heartbeat LED,Chipset voltage,CPU temperature,Dual cooling zones,Memory temperature,UID,VBAT |
| LED | Power LED |
| Temperature | CPU thermal trip support, Monitoring for CPU and chassis environment |
| FAN | 6x 4-pin fan headers (up to 6 fans) |
| Other Features | 12V DC or ATX Power Source, ACPI power management, ATX power connector, Chassis intrusion detection, M.2 NGFF connector, RoHS |
| Environmental |
| Operating Environment | Non-operating Relative Humidity: 5% to 95% (non-condensing) |
| Operating Relative Humidity: 10% to 85% (non-condensing) |
| Operating Temperature: 0°C to 60°C (32°F to 140°F ) |
| Non-operating Temperature: -40°C to 85°C (-40°F to 185°F) |
| Parts List |
| I/O Shield | 1x MCP-260-00194-0N |
| I/O Cables | 2x CBL-0044L |
| Optional Parts List |
| Optional Heat Sink | 1x SNK-P0086A4 |
| Optional Cable | 1x CBL-CDAT-0604, 1x CBL-CDAT-0850, 1x CBL-MCIO-1245U2Y-E, 1x CBL-OTHR-0985 |
| Optional Riser card | 1x RSC-S-6G5 |
