| Main Specifications |
| Device Type | Motherboard |
| Form Factor | Mini-ITX |
| Dimensions (WxDxH) | 6.7" x 6.7" (17.02cm x 17.02cm) |
| Processor |
| Compatible Processors | 8th/9th Generation Intel Core i9/Core i7/Core i5/Core i3/Pentium/Celeron Processor |
| Compatible Socket | Single Socket LGA-1151 (Socket H4) supported, CPU TDP supports Up to 65W TDP |
| System Memory |
| Memory Capacity | 2 DIMM slots |
| Up to 32GB Unbuffered non-ECC SODIMM, DDR4-2666MT/s |
| Memory Type | non-ECC DDR4 SODIMM Unbuffered |
| DIMM Sizes | 4GB, 8GB, 16GB |
| Memory Voltage | 1.2V |
| On-Board Devices |
| Chipset | Intel H310 |
| SATA/SAS | Intel H310 controller for 4 SATA3 (6 Gbps) ports |
| Graphics | 1 Intel HD Graphics port(s) |
| Network Controllers | Single LAN with Intel PHY I219LM LAN controller |
| Single LAN with Intel Ethernet Controller I210-AT |
| TPM | 1 TPM Header & Chip both |
| Input / Output |
| SATA | 4 SATA3 (6Gbps) port(s) |
| LAN | 2 RJ45 LAN ports |
| USB(s) | 4 USB 3.2 Gen2 port(s) (4 rear) |
| Video Output | 1 DVI - D port(s), 1 eDP (Embedded DisplayPort) port(s) |
| Serial Port / Headers | 4 COM, 2 COM Port(s) (2 rear) |
| DOM | 1 SuperDOM (Disk on Module) port with build power |
| Expansion / Connectivity |
| Expansion Slots Total (Free) | 1 PCIe 3.0 x16 |
| M.2 | M.2 Interface: 1 PCIe 2.0 x1 |
| Form Factor: 2230 |
| Key: E-Key |
| System BIOS |
| BIOS Type | AMI UEFI |
| BIOS Features | ACPI 6.1, SMBIOS 3.1, PCI FW 3.0, UEFI 2.6, RTC Wakeup BIOS setup option |
| Management |
| Software | SuperDoctor 5, NMI, Watchdog |
| System Management Software | SuperDoctor 5 |
| Power Configurations | ATX Power connector, +12V DC Power Input |
| PC Health Monitoring |
| Voltage | VBAT, System temperature, System level control, HT, 3 -fan status, +5V standby, +5V, +3.3V, +1.8V |
| LED | CPU/system overheat LED |
| Temperature | PECI |
| FAN | 3x 4-pin fan headers (up to 3 fans), Thermal control tachometer fan connectors, System level control, 3 fans with tachometer monitoring, Pulse Width Modulated (PWM) fan connectors |
| Other Features | WOL, System level control, RoHS, M.2 NGFF connector, CPU thermal trip support for processor protection, ATX Power connector, ACPI power management, 8-pin 12v DC power connector, 12V DC or ATX Power Source |
| Environmental |
| Operating Environment | Operating Relative Humidity Range: 10% - 85% (non-condensing) |
| Operating Temperature Range: 0°C - 60°C (32°F - 140°F) |
| Non Operating Relative Humidity Range: 10% - 95% (non-condensing) |
| Non-Operating Temperature Range: -30°C - 60°C (-22°F - 140°F) |
| Parts List |
| I/O Cables | 1x CBL-0044L |
| I/O Shield | 1x MCP-260-00136-0N |
