• Up to two Intel UPI channels
• 2.0GHz Xeon Silver 4109T 8-Core
• Enhanced Intel Run Sure Technology
• Support for Intel Optane SSDs & Intel 3D NAND SSDs
2.0GHz Xeon Silver 4109T 8-Core (16 Threads), LGA3647 Socket, 11MB Cache, 14nm, 9.6GT, 70W, HT, TurboBoost 3.0 (OEM, Tray)
• Improved memory speed
• Essential performance and power efficiency
• Moderate range compute, network, and storage
• Next-generation platform for cloud-optimized, 5G-ready networks
• Breakthrough HPC and high-performance data analytics innovation
• Strong, capable platforms for the hybrid-cloud, data-fueled enterprise
• Pervasive, breakthrough performance enables greater efficiencies and lower TCO
| Main Specifications | ||
| Clock Speed | 2.00 GHz | |
| Device Type | Server processor | |
| Form Factor | Intel Xeon Silver 4109T | |
| Manufacturing Process | 14 nm | |
| Multi-Core Technology | 8-core | |
| Number of Threads | 16 threads | |
| Processor Number | 4109T | |
| QPI/UPI | QPI: 9.6GT - Number of UPI Links: 2 | |
| Code Name | Products formerly Skylake | |
| Vertical Segment | Server | |
| Processor | ||
| Cache | 11 MB L3 | |
| Thermal | ||
| Design Power | 70 W | |
| Miscellaneous | ||
| Use Conditions | Communications | |
| Features | Intel Speed Shift Technology, Intel Turbo Boost Technology 2.0, Intel vPro Technology, Intel Hyper-Threading Technology, Intel Virtualization Technology, Intel TSX-NI, Intel 64 | |
| Package Type | OEM, Tray | |
| Memory Specifications | ||
| Max Memory Size (dependent on memory type) | 768 GB | |
| Memory Types | DDR4-2400 | |
| Maximum Memory Speed | 2400 MHz | |
| Max # of Memory Channels | 6 | |
| ECC Memory Supported | Yes | |
| Expansion Options | ||
| Scalability | 2S | |
| PCI Express Revision | 3.0 | |
| Max # of PCI Express Lanes | 48 | |
| Package Specifications | ||
| Sockets Supported | FCLGA3647 | |
| Case Temperature | 90°C | |
| Package Size | 76.0mm x 56.5mm | |
| Security Features | ||
| Security Features | Intel AES New Instructions, Intel Trusted Execution Technology, Execute Disable Bit, Mode-based Execute Control (MBE) | |
