| Main Specifications |
| Device Type | InfiniBand controller |
| Dimensions (WxDxH) | Card PCB dimensions: 92mm (3.62in) x 87.1mm (3.43in)(W x D) |
| Form Factor | Super I/O Module (SIOM) |
| InfiniBand | Hardware-based congestion control |
| 256 to 4Kbyte MTU, 2GB messages |
| IBTA Specification 1.2.1 compliant |
| Connectivity |
| Connectors | Interoperable with InfiniBand or 40GbE switches |
| Miscellaneous |
| Cables Required | Passive copper cable with ESD protection |
| GbE: RJ45 Category 5/5e up to 100m |
| InfiniBand FDR: QSFP 56Gbps Copper cables |
| Vendor Compatible Products | Supermicro motherboards with Super I/O Module slot |
| Supermicro server systems with Super I/O Module slot |
| Included Accessories | 1x AOC-MHIBF-m2Q2GM |
| 1x BKT-0118L |
| Compliant Standards | RoHS Compliant 6/6 |
| Storage Controller |
| Connectivity Technology | Wired |
| Data Transfer Rate | Up to 56Gbps InfiniBand or 40Gbps Ethernet |
| Networking |
| Enhanced InfiniBand | Hardware-based reliable transport |
| Collective operations offloads |
| Hardware-based reliable multicast |
| Extended Reliable Connected transport |
| Enhanced Atomic operations |
| Ethernet | IEEE 802.3ba 40 Gigabit Ethernet, IEEE Std 802.3ad Link Aggregation, IEEE Std 802.3az Energy Efficient Ethernet, IEEE Std 802.1Q, .1P VLAN tags and priority, IEEE P802.1bb D1.0 Priority-based Flow Control, IEEE 1588, Jumbo frame support (9600B) |
| Hardware-based I/O Virtualization | Address translation and protection |
| Multiple queues per virtual machine |
| Single Root IOV |
| Enhanced QoS for vNICs |
| VMware NetQueue support |
| Dedicated adapter resources |
| Port Quantity | Dual RJ45 connectors |
| Power |
| Comsumtion Operational | Maximum 9W |
| Expansion / Connectivity |
| Interface and Connections | Dual QSFP connector |
| Environmental Parameters |
| Operating Temperature | Operating temperature: 0C to 55C (32F to 131F) |
| Storage temperature: -40C to 70C (-40F to 158F) |
| Storage humidity: 90% non-condensing relative humidity at 35C |
| Software / System Requirements |
| OS Supports | FreeBSD |
| OpenFabrics Enterprise Distribution (OFED) |
| OpenFabrics Windows Distribution (WinOF) |
| Citrix XenServer 6.1 |
| RHEL/CentOS 5.X and 6.X, Novell SLES10 SP4, SLES11 SP1, SLES 11 SP2, OEL, Fedora 14, 15, 17, Ubuntu 12.04 |
| Windows Server 2008/2012/2012 R2 |
| VMware ESXi 4.x and 5.x |
