| Main Specifications |
| Device Type | SuperChassis |
| Form Factor | 1U Chassis |
| Supported Motherboards | Support motherboard sizes: Proprietary Micro ATX 9.6" x 9.6" |
| Dimensions (WxDxH) | Height 1.7" (43 mm) x Width 17.2" (437 mm) x Depth 19.98" (507 mm) |
| Weight | Gross Weight 28 lbs (12.65 kg) - Net Weight 24.35 lbs (10.5 kg) |
| Enclosure Color | Black |
| Processor |
| Compatible Processors | Dual and Single Intel and AMD processors |
| Expansion / Connectivity |
| Expansion Slots Total (Free) | 1x Full-height expansion slot, 1x Low-profile expansion slot |
| Expansion Bays Total (Free) | 4x 3.5" hot-swap SAS3/SATA drive bay - SAS or enterprise SATA HDD only recommended |
| Peripheral Bay (Free) | Optional 1x slim DVD-ROM drive bay, Optional 1x USB + COM port tray |
| Backplane |
| SAS/SATA HDD Backplane | 4-Port 1U Hybrid Backplane Support 4x3.5"SAS3/SATA3/NVMe Storage Devices, HF, RoHS (NOTE: 2.5" NVMe SSD require conversion tray) |
| Front Panel |
| Buttons | Power On/Off button, System Reset button |
| LEDs | Power status LED, HDD activity LED, System Information LED, 2 Network Activity LEDs |
| System Cooling |
| Fans/Air Shroud | 4x 40x28mm PWM fan(s), Optional 2x fans for AOC cooling |
| Fans | 4x FAN-0154L4 |
| Environmental |
| Operating Environment | Operating Temperature Range: 5°C - 35°C (41°F - 95°F) |
| Non-Operating Temperature Range: -40°C - 70°C (-40°F - 158°F) |
| Operating Relative Humidity Range: 8% - 90% (non-condensing) |
| Non-Operating Relative Humidity Range: 5% - 95% (non-condensing) |
| Power Supply |
| Power Supply | 1U 350W Multi-output power supply Platinum level |
| Certification | 80PLUS Platinum Certified |
| Regulatory Safety / EMC | BSMI, CCC, CE/EMC, FCC class B, TUV/CB |
| Parts List - (Items Included) |
| Bracket(s) | 1x MCP-240-00197-0N |
| Hard Drive Backplane | 1x BPN-SAS3-815TQ |
| Cable(s) | 1x CBL-0071L, 1x CBL-PWCD-0160-IS |
| Parts | 1x MCP-120-00115-0N, 1x MCP-120-00116-0N, 1x MCP-230-81305-0N, 1x MCP-270-81308-0N, 1x MCP-290-00088-0N, 1x CSE-PT93L-B, 1x MCP-320-00060-0N, 2x MCP-340-00001-01 |
| Drive Trays | 4x MCP-220-00075-0B |
| Mounting Rails | 1set MCP-290-00102-0N, 1set MCP-290-00108-0N, 1set MCP-290-00110-0N |
| Rear Window | 1x MCP-240-00196-0N |
| Power Supply Number | 1x PWS-350-1H |
