Intel PK8072205560300 Xeon Scalable Gold 6538N 2.10GHz 32-Core Processor 5th Generation - Emerald Rapids

Intel PK8072205560300 Xeon Scalable Gold 6538N 2.10GHz 32-Core Processor 5th Generation - Emerald Rapids

  • Built-in Intel Accelerator Engines for Performance and Security

  • Support for higher memory speeds and enhanced memory capacity

  • Optimized for demanding AI, mainstream data center, multi-cloud compute

Processor 2.10GHz Intel Xeon Gold 6538N 32-Core (64 Threads) CPU Socket: FCLGA4677 60MB 20 GT/s 7nm 205W For DP Systems - Intel Xeon Scalable 5th Generation Series OEM, Tray

$ 2,857.00$ 2,857.002857.0USD

$ 2,857.00

Option not available

InStock
1 lb

Contact us for volume discounts

    This combination does not exist.

    Add to Cart

    Intel Xeon Gold processors are optimized for demanding AI, mainstream data center, multi-cloud compute, and network and storage workloads. With support for higher memory speeds and enhanced memory capacity, these processors deliver advanced performance, energy-efficient compute, enhanced memory capabilities, hardware-enhanced security, and workload acceleration.

    Extra Specifications for Intel PK8072205560300 Xeon Scalable Gold 6538N 2.10GHz 32-Core Processor 5th Generation - Emerald Rapids

    Main Specifications
    Device TypeProcessor
    Processor Number6538N
    Clock Speed2.10 GHz
    Max Turbo Speed4.10 GHz
    Multi-Core Technology32-Core
    Number of Threads64
    Manufacturing Process7 nm
    Intel UPI Speed20 GT/s
    QPI/UPINumber of UPI Links: 3
    Product Collection5th Generation Intel Xeon Scalable Processors
    Code NameProducts formerly EMERALD RAPIDS
    Vertical SegmentServer
    Processor
    Cache60 MB
    Thermal
    Design Power205 W
    Memory Specifications
    Max Memory Size (dependent on memory type)4 TB
    Memory TypesUp to DDR5 5200 MT/s 1DPC
    Max # of Memory Channels8
    ECC Memory SupportedYes
    Expansion Options
    Scalability2S
    PCI Express Revision5
    Max # of PCI Express Lanes80
    Package Specifications
    Sockets SupportedFCLGA4677
    Package CarrierE1B
    DTS Max95 °C
    Case Temperature85°C
    Package Size77.5mm x 56.5mm
    Miscellaneous
    Use Conditions Server/Enterprise
    Package TypeOEM, Tray

    Warranty:90 days
    Coverage:Replacement or repair
    Average Service Time:1-2 weeks
